By Core Brake Parts Tech Team — Circleville, OH warehouse
An ABS light on a 2009-2021 Nissan 370Z most often traces back to a wheel speed sensor circuit: a damaged sensor, a dirty sensor tip or magnetic encoder, a chafed harness, or a worn hub bearing that lets the encoder wobble. Low brake fluid, mismatched tires and a failing ABS actuator are the other usual suspects. When the light is on, Nissan says the anti-lock function is switched off and the car brakes normally but without anti-lock assistance, so diagnose it before your next hard stop in the rain.
How the ABS and VDC System Works on the 370Z
The 370Z uses ABS integrated with Vehicle Dynamic Control (VDC) and traction control. According to Nissan's owner's manual, the system detects the rotation speed at each wheel and varies brake fluid pressure so no wheel locks and slides. The hardware is a set of electronic wheel speed sensors, an electric pump, hydraulic solenoids and a control computer, packaged as the ABS actuator and electric unit.
Every time you start the car and roll away at low speed, the computer runs a self-test. You may hear a clunk or feel a pulse in the pedal during that test; Nissan calls that normal. If the self-test or the running system finds a fault, it shuts ABS off and lights the ABS warning lamp. The anti-lock function itself works above roughly 3 to 6 mph.
Because VDC and traction control share those same wheel speed signals, a single bad sensor usually lights more than one lamp. It is common to see ABS, VDC (the slip indicator) and sometimes the red BRAKE light together from one root cause.
What the Warning Light Combination Tells You
| Lights on | What Nissan says it means | First thing to check |
|---|---|---|
| ABS only, stays on while driving | ABS may not be functioning properly; anti-lock is turned off, normal braking remains | Scan for wheel speed sensor codes |
| VDC light on steady with VDC switched on | VDC fail-safe mode is operating; the system may not be functioning properly | Same wheel speed sensor codes, then tires |
| Red BRAKE light, parking brake released | Low brake fluid level | Fluid level at the reservoir, then pad wear and leaks |
| Red BRAKE plus ABS, fluid level correct | ABS may not be functioning properly | Have the brake system checked before normal driving |
| VDC light blinking briefly | VDC or traction control is actively working near the traction limit | Nothing - this is normal operation |
Nissan's own warning is blunt: if the brake warning light is on, the brake system may not be working properly. If the red BRAKE light comes on with the parking brake released, stop, check the fluid, and do not keep driving on a low reservoir.
The Most Common Causes, in Order
1. Wheel speed sensor or its signal path
Nissan's technical service bulletin NTB10-102a covers 2007-2013 Nissan vehicles equipped with ABS/VDC, which takes in the early 370Z years, and addresses wheel speed sensor codes C1101 through C1108. Its most important instruction is the one most often ignored: do not replace a sensor based on the code alone without confirming a specific issue. The bulletin's diagnosis walks through the sensor body for damage, whether the sensor produces a signal when the wheel is spun, the harness for shorts, and both connectors for bent pins, corrosion or contamination. A sensor lead that rubbed on a suspension part, or a connector packed with road grime, will set the same code as a dead sensor.
2. Contaminated sensor tip or encoder ring
The same Nissan bulletin tells technicians to check the sensor head for contamination and clean it, then check the tone ring (magnetic encoder) for contamination, noting that debris there can cause intermittent errors. Magnetic encoders attract fine metallic particles from brake wear and rust, so this is a real cause on a car that sees hard braking.
3. Worn hub bearing
If the sensor and encoder look fine, Nissan's procedure moves to the tone wheel and bearing: damage, missing teeth, cracks, corrosion or looseness. As Brake and Front End explains, a worn bearing develops internal play that lets the encoder wobble relative to the fixed sensor and constantly changes the air gap, which destabilizes the signal most at low speeds. A 370Z that throws an intermittent ABS light and also has a growl that changes with steering load is a strong bearing candidate.
4. Tires and wheels
The bulletin also calls for checking tire pressure and tire wear on C1105-C1108 codes. A tire with a different rolling diameter spins at a different speed, and the module can read that as a fault. Nissan's manual says to install the specified size on all four wheels and warns that wheels or tires other than the recommended ones can make VDC operate improperly and light the VDC warning. Aftermarket wheel packages with the wrong overall diameter are a known trigger.
5. Low brake fluid and worn brake parts
Fluid level drops as pads wear. Nissan also states that if brake parts such as pads, rotors and calipers are not Nissan recommended or are extremely deteriorated, VDC may not operate properly and the VDC warning light may illuminate. Worn-out brakes can therefore show up as a combination of BRAKE and VDC lamps.
6. ABS actuator and electric unit
The actuator is the last thing to condemn, not the first. In Nissan's procedure it is replaced only when the supply voltage checks point to it, or when the same code comes right back after the sensor, encoder, bearing and wiring have all been verified.
How to Diagnose It Yourself
- Check the reservoir. With the car level, fluid should sit between MIN and MAX. If it is low, look at pad thickness before topping up, then look for leaks at the calipers, hoses and lines.
- Read the codes. A basic engine code reader often cannot see ABS codes. You need a scan tool that reads the ABS module. Write down every code and which wheel it names.
- Clear and re-test. Nissan's bulletin says the code must be active to diagnose it: clear it, then drive above 13 mph and see whether it resets.
- Compare live wheel speeds. On a scan tool with live data, all four wheels should read about the same on a straight road. The one that drops out or reads erratically is your suspect corner.
- Inspect that corner. Look along the sensor lead for chafing, unplug and inspect the connector, pull the sensor and clean its tip, and look at the encoder for debris.
- Check the bearing. With the wheel off the ground, rock it at 12 and 6 o'clock. Any play, or a growl on the road, points to the hub.
- Confirm the repair. Nissan's verification test is to clear codes, run the engine, then road test for at least 5 minutes and re-check for codes.
The Fix and What to Replace Together
Most 370Z ABS lights are fixed with a wheel speed sensor, a cleaning of the sensor and encoder, a wiring repair, or a hub bearing. A few practical points:
- When installing a hub unit that comes with the sensor already in place, do not pull the sensor out first, since that can alter the factory-set air gap.
- If the brake job is due and you are already working at that corner, pads and rotors are easiest to do while the sensor and hub are accessible. Browse brake pads and brake rotors, or all brake parts.
- For Sport-brake cars, we carry the DBA 5000 Series T3 front slotted 2-piece rotor for the 370Z Sport and the DBA Street Series T2 slotted rear rotor for 370Z Sport brakes. Confirm your brake package before ordering.
- Use the right fluid. Nissan specifies Genuine Nissan Super Heavy Duty Brake Fluid or an equivalent DOT 3 for non-NISMO cars, and Genuine Nissan Brake Fluid R35 Special II for NISMO models, warning that the NISMO VDC unit was designed for that fluid and never to mix fluid types.
Difficulty: checking fluid and reading codes is a beginner job. A bolt-in wheel speed sensor is an easy to moderate job with basic hand tools, though sensors can seize in their bores on older cars. A hub bearing is moderate to hard. An ABS actuator replacement means opening the hydraulic system and may need scan-tool bleeding and initialization, so it is best left to a shop.
Need the part? Shop Brake Parts at Core Brake Parts
Filter by your exact year, make, and model — every part ships from our Circleville, OH warehouse, free over $75.
Shop Brake Parts →Frequently Asked Questions
Is it safe to drive a 370Z with the ABS light on?
Nissan says the brakes still work normally but without anti-lock assistance, so the car can lock wheels in a panic stop or on wet roads. Drive gently and get it diagnosed. If the red BRAKE light is also on, check the fluid before driving at all.
Why are the ABS and VDC lights on at the same time?
VDC and traction control rely on the same wheel speed signals as ABS. When one sensor signal is lost, VDC drops into fail-safe mode, so one fault lights several lamps.
Can new tires or wheels cause an ABS or VDC light?
Yes. Nissan's manual says wheels or tires other than the recommended ones can make VDC work improperly and light its warning, and the service bulletin lists tire pressure and wear as a check for sensor codes.
Will clearing the code fix the ABS light?
Only temporarily if the fault is real. Nissan's procedure clears the code on purpose to see whether it comes back after a drive; if it does, the fault is active and needs a repair.
Should I replace the wheel speed sensor as soon as I see a code?
No. Nissan's bulletin specifically says not to replace a sensor based on the code alone. Check wiring, connectors, contamination and the hub bearing first.
Can worn brakes turn on a warning light on the 370Z?
Indirectly, yes. Pad wear lowers the fluid level, which can light the red BRAKE light, and Nissan notes extremely deteriorated pads, rotors or calipers can cause the VDC warning light.
Sources
- Nissan TSB NTB10-102a, ABS/VDC Wheel Speed Sensor Diagnosis (NHTSA) - codes C1101-C1108, do not replace on code alone, sensor, encoder, bearing and tire checks, verification road test
- Nissan 2018 370Z Owner's Manual - ABS, BRAKE and VDC warning light meanings, ABS self-test and operating speed, tire and brake part cautions, brake fluid specification
- Brake and Front End - Diagnosing Hub Units and Wheel Speed Sensors - bearing play changing the air gap, encoder contamination, hub unit installation caution
