2004-2015 Nissan Titan Parking Brake Problems and Adjustment

By Core Brake Parts Tech Team — Circleville, OH warehouse

On a 2004-2015 Nissan Titan, the parking brake is not part of the rear calipers. It is a small set of drum shoes hidden inside the hat of each rear disc rotor, pulled by cables from a foot pedal. Most Titan parking brake complaints - a pedal that goes nearly to the floor, a truck that creeps on a hill, or a rear rotor that will not come off - come down to those shoes being worn, rusted or out of adjustment, and the fix is a shoe adjustment followed by a cable adjustment, in that order.

How the Titan parking brake works

The first-generation Titan uses rear disc brakes for normal stopping and a separate "drum in disc" parking brake. Nissan's factory service manual lists the parking brake type as drum and the control type as a foot pedal. The inside of each rear rotor hat is machined as a small brake drum, and two parking brake shoes sit on the backing plate inside it.

When you press the pedal, a front cable pulls an equalizer, which splits the pull between a right and a left rear cable. Each rear cable pulls a toggle lever on the shoes, spreading them against the drum surface inside the rotor hat. A star-wheel adjuster between the shoes sets how close the linings sit to the drum. Because the service brakes never touch this drum, the parking shoes wear very slowly - but they also never get scrubbed clean by regular use, which is why rust is the most common enemy.

The factory specifications for the parking brake, from the 2005 and 2009 Titan service manuals (the numbers are the same in both):

The manuals we checked cover the 2005 and 2009 model years. The parking brake layout is shared across the first-generation trucks, but always confirm specs against the factory manual for your exact year.

Common Titan parking brake problems and their symptoms

Pedal goes too far before it holds

The factory spec is 3 to 4 clicks of the ratchet with a firm push. If you are counting six, eight or more clicks, or the pedal nearly bottoms out, the system has too much slack. The cause is almost always shoe clearance first (worn linings, or an adjuster that was never reset after the last rotor job) and cable stretch second. Simply tightening the cable without setting the shoes hides the problem and can leave the shoes dragging.

Truck rolls on a grade with the pedal set

Same root causes as a long pedal, plus contaminated linings. A leaking rear axle seal or a weeping caliper can soak the parking shoes in gear oil or brake fluid, and oil-soaked linings will not grip no matter how well they are adjusted. If you find oil inside the rotor hat, fix the leak and replace the shoes.

Rear rotor will not come off

This shows up during a rear pad and rotor job. Rust builds a lip on the drum surface inside the hat, and the shoes catch on it. Nissan's manual says to remove the disc rotor only with the parking brake pedal completely released. If it still hangs up, the shoes need to be backed off at the adjuster before the rotor will slide over them. Forcing it off often bends the backing plate or tears up the shoe hardware.

Dragging, heat or a burning smell from one rear wheel

A seized cable, a weak return spring or shoes adjusted too tight can keep the linings in contact with the drum. The factory procedure calls for confirming the rotor turns with no drag after shoe adjustment, and confirming again with the pedal fully released after cable adjustment.

Warning light stays on

The parking brake warning lamp switch comes on at the first notch of pedal travel. If the light stays on with the pedal fully released, check that the pedal is returning all the way and inspect the switch. A low brake fluid level can also light the brake warning, so check the reservoir too.

How to adjust the parking brake the factory way

Nissan's procedure adjusts the shoes to the drum first, then sets the cable. Doing it in the opposite order is the most common mistake.

1. Remove the rear wheel. Using a deep socket on the cable adjusting nut, loosen the cable enough to give slack, then let the pedal return fully. Nissan says not to reuse the adjusting nut once it has been removed, so loosen it rather than taking it off.
2. Remove the rear rotor and measure the inner diameter of the drum surface at its widest point. Nissan specifies a brake drum clearance gauge (Kent-Moore J-21177-A) for this.
3. Set the shoes to that measurement minus 0.6 mm (0.024 in) by turning the star-wheel adjuster. That leaves a small, even running clearance.
4. Reinstall the rotor, hold it flat against the hub with the wheel nuts, and turn it by hand to confirm there is no drag.
5. Pump the parking brake pedal 10 or more times with a hard push (Nissan specifies 490 N, about 110 lb) to seat the cables.
6. Turn the cable adjusting nut until the pedal stroke is 3 to 4 notches under a firm push (196 N, about 44 lb).
7. Release the pedal completely and confirm the rear brakes do not drag.

Never pull the parking brake with a rotor removed - the shoes will spread out of position and you will be pulling the hardware apart to reset them. Wilwood gives the same warning for its own internal drum parking brakes.

Burnishing new shoes after a brake job

New parking shoes, or old shoes against a new rotor, do not hold well until they have been broken in. Nissan calls for a burnishing procedure after replacing the shoes or rotors, or whenever the parking brake does not hold well:

• Adjust the pedal stroke first, as above.
• Drive forward at 40 km/h (25 MPH) with the parking brake applied at about 196 N (44 lb) of pedal force for 30 seconds.
• Let the linings cool for about 5 minutes after each break-in run, and do not overdo it - Nissan warns that excessive break-in causes uneven or early lining wear.
• Recheck the pedal stroke and readjust if it has moved out of spec.

Do this on an empty road or lot with no traffic behind you.

What to replace at the same time

Because the parking brake lives inside the rear rotor, any rear rotor job is the time to inspect it. The factory inspection list makes a useful checklist:

• Shoes: replace if the lining is at or below 0.5 mm, cracked, glazed or contaminated with oil or fluid.
• Rotor drum surface: replace the rotor if the inner diameter is past 205.7 mm or the drum surface is badly scored or cracked. Browse our brake rotors for rear Titan rotors.
• Hardware: check return springs for sagging, anti-rattle pins for wear and corrosion, and the adjuster for rough operation. Nissan specifies PBC (Poly Butyl Cuprysil) grease or equivalent on the adjuster threads and brake grease at the backing plate contact points. A brake hardware kit is cheap insurance on a truck this age.
• Cables: replace any cable that is frayed, kinked or will not slide freely.
• Rear pads: if the rotors are off, the pads are usually due. These Titan rear brake pads for 2004-2015 fit this truck, and you can see more options in our brake pads collection.

How hard is the job?

A cable-only adjustment is a short job if the shoes are already in good shape. A full shoe adjustment is a moderate DIY job: you are already removing the rear calipers and rotors, so it fits naturally into a rear brake job. The hard part is rust - a rotor seized to the hub or shoes stuck on a rust lip can turn a quick job into an afternoon. Replacing shoes and springs takes patience with the hardware, so photograph how everything came apart before you remove it. Torque the caliper bracket bolts and wheel nuts to the values in the factory service manual.

A note for owners of newer trucks: NHTSA recall 22V-457 covers certain 2020-2022 Titan and Frontier trucks whose transmission parking pawl may not engage. That recall does not apply to first-generation 2004-2015 trucks, but its advice is good for any Titan - set the parking brake every time you park, especially when towing or on a slope. A parking brake that is used regularly also stays freer of rust.

Frequently Asked Questions

How many clicks should the Nissan Titan parking brake pedal take?

Nissan specifies 3 to 4 notches with a firm push of about 44 lb on the pedal. More than that means the shoes or cable need adjustment.

Does the 2004-2015 Titan have rear drum brakes?

No. The service brakes are rear discs. The only drum is the small parking brake drum machined into the inside of each rear rotor hat.

Can I just tighten the parking brake cable?

You can, but it is a shortcut. If the shoes are far from the drum, cranking the cable uses up its travel and can leave the shoes dragging. Set the shoe clearance first, then the cable.

Why will my Titan rear rotor not come off?

Usually the parking shoes are catching on a rust lip inside the rotor hat, or the rotor is rusted to the hub. Make sure the parking brake is fully released, back the shoes off at the adjuster, and use penetrating oil at the hub center.

Do I need new parking brake shoes when I replace the rear rotors?

Not always. Replace them if the lining is near the 0.5 mm limit, glazed, cracked or oil-soaked. If you reuse them, adjust them to the new rotor and run the burnishing procedure.

How do I break in new parking brake shoes?

Drive at 25 MPH with the parking brake lightly applied for 30 seconds, let it cool about 5 minutes, and recheck the pedal stroke afterward. Do not repeat it excessively.

Sources

1. Nissan 2005 Titan Service Manual, Section PB (Parking Brake System) - parking brake type, foot pedal control, pedal stroke, adjustment and burnishing procedure, shoe and drum specs, rotor removal caution
2. Nissan 2009 Titan Service Manual, Section PB - confirms the same shoe, drum and pedal stroke specifications and the 0.6 mm (0.024 in) clearance setting
3. Wilwood - How to Adjust the Internal Drum Parking Brake - star-wheel shoe adjustment and the warning not to actuate the lever with the drum removed
4. NHTSA Recall 22V-457 owner notification (Nissan) - 2020-2022 Titan and Frontier parking pawl recall and the advice to apply the parking brake every time you park
