Short answer: The Lincoln Navigator runs four-wheel vented disc brakes with 6-lug M14x2.0 wheels torqued near 150 ft-lbs. Pre-2018 models use a drum-in-hat parking brake; 2018-plus models use an electronic parking brake requiring service mode. This guide walks through the exact diagnostic steps, replacement thresholds, product comparisons, and cost breakdown so you can decide with confidence whether to DIY or take it to a shop.
Direct experience note: we ship these parts daily from our Circleville, OH warehouse to customers across the country. The picks in this guide reflect what fits, what lasts, and what our repeat-buyer mechanics come back for.
The parts that fix this — verified to fit your Lincoln Navigator
Shop the part →or see all Lincoln Navigator brake partsShips from our Circleville, OH warehouse. Free shipping over $75.
What to Know About Lincoln Navigator Brake Replacement
Understanding Lincoln Navigator brake replacement matters because it directly affects stopping distance, brake pedal feel, and how often you replace consumables. Getting it right the first time saves both money and follow-up shop visits.
- Front rotors are vented discs, roughly 13.78 in (350 mm) on 2007-2021 models; earlier generations run slightly smaller.
- Rear brakes are also disc, typically vented; confirm the exact size for your specific year and trim.
- Wheels use six lugs on a 6x135 mm pattern with M14x2.0 studs across all generations.
- Lug torque is about 150 ft-lbs; re-torque within 100 miles of any wheel removal.
- 2018-plus Navigators use an electronic parking brake (EPB) that needs service mode to retract the caliper pistons.
- Pre-2018 Navigators use a drum-in-hat parking brake with small shoes inside the rear rotor hat.
Spec Chart by Vehicle Class
| Vehicle class | Pad thickness | Rotor thickness |
|---|---|---|
| Rotor type | Front: vented disc | Rear: vented disc |
| Rotor diameter | Front ~13.78 in (350 mm) | Rear varies by year/trim |
| Wheel fitment | 6 lugs, 6x135 mm | M14x2.0 studs |
| Lug torque | ~150 ft-lbs | Re-torque at 100 miles |
| Parking brake | Drum-in-hat (pre-2018) | Electronic EPB (2018+) |
How to Diagnose or Replace
- Loosen the six lug nuts, lift the corner, set a jack stand, then remove the wheel.
- For 2018-plus models, put the electronic parking brake into service mode with a scan tool first.
- Remove the two caliper slide bolts, lift the caliper off, and hang it with wire.
- Slide out the old pads, then compress the piston; twist-and-push rear EPB pistons, straight-push fronts.
- Unbolt the caliper bracket, pull the rotor, and clean the hub mating surface thoroughly.
- Fit the new vented rotor and pads, reinstall the caliper, and torque every fastener to spec.
- Torque lugs near 150 ft-lbs, exit service mode, then pump the pedal firm.
Once diagnosis is complete, order the exact replacement parts for your vehicle - fitment matters. Related Lincoln Navigator brake replacement products are listed in the next section.
Recommended Parts and Where to Buy
Every product below is in stock at our Circleville, OH warehouse and ships same-day when ordered before 2 PM Eastern. Free shipping on orders over $75.
If your exact vehicle is not listed, use the site search or filter the full brake parts collection by year and make.
Cost Breakdown - DIY vs Shop
| Job | DIY parts only | Shop parts and labor |
|---|---|---|
| Front pads (pair) | $40-$90 parts | $180-$320 shop |
| Rear pads (pair) | $40-$90 parts | $180-$320 shop |
| Front rotor pair | $90-$220 parts | $350-$600 shop |
| Full axle brake job | $150-$400 parts | $450-$900 shop |
DIY savings scale with vehicle size and job complexity. A full-size truck brake job saves $450-700 in labor. For most passenger cars, plan on 90-120 minutes per axle for pads only, 2-3 hours for pads plus rotors.
Install Tips - Where Most DIYers Go Wrong
- Never hammer a stuck rear rotor before confirming the drum-in-hat parking shoes are fully backed off.
- On 2018-plus trucks you must enter EPB service mode, or the caliper motor can be damaged.
- Grease the slide pins with silicone, keep anti-seize off all friction surfaces, and bed the pads in gently.
Frequently Asked Questions
What's the short answer on Lincoln Navigator brake replacement?
The Lincoln Navigator runs four-wheel vented disc brakes with 6-lug M14x2.0 wheels torqued near 150 ft-lbs. Pre-2018 models use a drum-in-hat parking brake; 2018-plus models use an electronic parking brake requiring service mode.
How much does Lincoln Navigator brake replacement cost?
It depends on your vehicle and how much you replace. For example, front pads (pair) runs about $40-$90 parts in parts for a DIY job, or $180-$320 shop at a shop with labor included. The full cost breakdown is in the table above.
What should I check first?
Key things to check: Front rotors are vented discs, roughly 13.78 in (350 mm) on 2007-2021 models; earlier generations run slightly smaller; Rear brakes are also disc, typically vented; confirm the exact size for your specific year and trim.
Can I do this job myself?
Many DIYers can with basic tools. The first steps are: Loosen the six lug nuts, lift the corner, set a jack stand, then remove the wheel; For 2018-plus models, put the electronic parking brake into service mode with a scan tool first; Remove the two caliper slide bolts, lift the caliper off, and hang it with wire. The complete step-by-step is above.
Key Takeaways
- The Lincoln Navigator runs four-wheel vented disc brakes with 6-lug M14x2.0 wheels torqued near 150 ft-lbs. Pre-2018 models use a drum-in-hat parking brake; 2018-plus models use an electronic parking brake requiring service mode.
- Measure friction material and rotor thickness at every tire rotation - catches wear before it becomes damage.
- Replace pads at 3 mm; below 2 mm is unsafe.
- Loaded calipers (with brackets, pads, and hoses) save 1-1.5 hours of labor per side over bare calipers.
- Bed new pads properly with 8-10 medium stops from 40 to 10 mph.
