1993-2000 Lexus LS400 ABS Light On: Common Causes and Fixes

By Core Brake Parts Tech Team — Circleville, OH warehouse

When the ANTILOCK light stays on in a 1993-2000 Lexus LS400, the ABS computer has found a fault and switched anti-lock braking off. Your normal brakes still work, but the wheels can lock in a hard stop. The most common cause is a wheel speed sensor signal problem, and the fastest way to find it is to pull the stored code before buying any parts.

How the LS400 ABS System Works

Each wheel on the LS400 has a speed sensor that reads a toothed ring (the tone ring or sensor rotor) as it spins. The sensor sends a signal that rises in frequency as the wheel turns faster, and the ABS computer compares all four wheels. When one wheel slows sharply compared to the others during braking, the computer pulses pressure to that wheel through its solenoid valves in the ABS actuator, keeping it rolling so you can still steer.

The system watches itself constantly. If a sensor signal drops out, a solenoid circuit opens, the pump motor or its relay fails, or battery voltage goes out of range, the computer stores a code, lights the ANTILOCK lamp and disables ABS. Cars equipped with TRAC traction control share that hardware, so a TRAC light often comes on with the ABS light when a wheel speed signal is lost.

Reading the ABS Codes

How you read codes depends on the year:

• 1993-1994 (OBD I): With the ignition off, jumper terminals Tc and E1 in the diagnostic connector (the TDCL under the steering wheel, or the check connector in the engine bay). Turn the ignition on and count the blinks on the ANTILOCK light. Codes are two digits: the first digit flashes, a short pause, then the second digit. Multiple codes play lowest first and then repeat. A steady fast blink means no codes are stored.
• 1995-2000 (OBD II): These cars use the OBD II diagnostic port and a scan tool. A basic engine-only code reader may not show ABS codes, so use a scan tool that reads the ABS module, or have a shop pull them.

On the 1993-1994 cars, the ABS and TRAC codes are cleared by leaving the jumper in Tc and E1 and pressing the brake pedal eight or more times within three seconds. Clearing only matters after the repair: if the light comes back on the road test, the fault is still there.

What the Common ABS Codes Mean

These are the OBD I ABS codes published for the LS400. They point to the circuit, not always the failed part, so treat each one as the place to start testing.

On 1995-2000 cars the scan tool will show the equivalent fault in its own format, but the causes behind it are the same.

Common Causes and How to Diagnose Them

Wheel speed sensor signal faults (codes 31-36)

This is where most LS400 ABS lights end up. The sensor itself can fail, but just as often the signal is weak because of something around it:

• Metallic debris on the sensor tip. Brake dust and wear particles stick to the magnetic tip and weaken the signal. Pull the sensor, clean the tip and the bore, and recheck.
• Wiring and connectors. The sensor harness runs through the wheel well and flexes with the suspension. A cracked jacket, a chafed wire or a corroded connector adds resistance or opens the circuit. Codes 35 and 36 in particular point to an open circuit rather than a bad signal.
• Air gap changes. A worn wheel bearing lets the hub move, so the gap between the sensor and the tone ring grows and shrinks, and the signal drops out intermittently. Check for bearing play whenever a sensor code keeps coming back.
• Tone ring damage or rust. Missing, cracked or rust-swollen teeth distort the signal. Code 37 names the front sensor rotor directly.

To test a sensor, measure its resistance at the connector with the key off and compare it to the factory service manual value, then spin the wheel by hand and check for an AC voltage signal. An open reading, a short, or no output while spinning means the sensor or its wiring is bad. An oscilloscope shows a weak or flattened waveform that a meter can miss. Do not assume the code means a new sensor; confirm it first.

Solenoid, relay and pump motor codes (11-24, 51)

These point into the ABS actuator and its relays. Check the fuses and relays first, then the connectors and grounds at the actuator. A locked pump motor or an internal solenoid fault usually means the actuator is the repair, which is a bigger job because the hydraulic unit must be replaced and the system bled correctly afterward.

Voltage problems (code 41)

A weak battery, a failing alternator or poor battery terminals can set an ABS code on these cars. Test charging voltage before chasing anything else, especially if several warning lights came on together.

ABS Light vs BRAKE Light

The ANTILOCK light is about the anti-lock electronics. The red BRAKE light is a different warning: parking brake applied, or low fluid in the master cylinder reservoir. If the red BRAKE light is on, check the fluid level right away. Low fluid usually means the pads are very worn (the caliper pistons have moved out and taken fluid with them) or there is a leak. Top up only with the fluid type printed on the reservoir cap, and find out why it was low before driving far.

The Fix and What to Replace at the Same Time

Match the repair to the code:

• Dirty sensor: clean the tip and mounting bore, clear the codes, road test.
• Damaged harness or connector: repair or replace the sensor lead; a chafed wire will fail again if you only tape it.
• Failed sensor: replace it, route the new lead in the original clips so it cannot rub on the tire or suspension, and clear the codes.
• Worn wheel bearing: replace the bearing or hub, because a new sensor will not fix a moving air gap.
• Actuator or pump fault: confirm with testing before replacing the actuator, and bleed the system to the factory procedure afterward.

The wheel speed sensors sit right behind the brakes, so the job is a good time to check pad thickness and rotor condition. Brake work that disturbs the sensor harness is also a common way a new ABS light appears, so check the sensor leads after any pad or rotor job. If your pads are due, we carry EBC pads that fit the LS400, including EBC Redstuff ceramic front pads for the 1995-2000 LS400, EBC Yellowstuff front pads for the 1995-2000 LS400 and EBC Redstuff ceramic rear pads for the 1993-1994 LS400. You can also browse brake rotors and brake hardware kits for the rest of the job.

How Hard Is the Job?

Reading codes on a 1993-1994 LS400 takes a short jumper wire and a few minutes. Cleaning or replacing a wheel speed sensor is a moderate driveway job: lift the car, remove the wheel, unbolt the sensor, and follow the lead back to its connector. Rusted sensors can seize in their bores, so penetrating oil and patience help. A wheel bearing or hub is a bigger job, and an ABS actuator replacement involves brake lines and a proper bleed, which many owners leave to a shop with a scan tool.

Before any repair, check for open recalls on your VIN at NHTSA. When we checked NHTSA recall listings for the 1993, 1995, 1998 and 2000 LS400, none were ABS or brake-system campaigns, so an ABS light on these cars is almost always a wear or wiring repair rather than a recall item.

Frequently Asked Questions

Is it safe to drive an LS400 with the ABS light on?

The normal brakes still work, but anti-lock is disabled, so the wheels can lock in a panic stop or on wet or icy roads. Drive gently, leave extra following distance, and get the code read soon. If the red BRAKE light is also on, check the fluid level before driving.

Will new brake pads turn off the ABS light?

Not by themselves. Worn pads affect the red BRAKE light through low fluid, not the ANTILOCK light. But a brake job can disturb a sensor lead or let debris onto a sensor tip, so if the ABS light came on right after brake work, inspect the sensors and connectors first.

Can a weak battery cause the ABS light?

Yes. The LS400 ABS computer stores a code for battery voltage that is too low or too high. Test the battery and charging system if the light comes on with other warnings or after a hard start.

Why does the ABS light come on and then go off?

An intermittent fault, most often a sensor wire that opens as the suspension moves, a dirty sensor, or a worn wheel bearing changing the air gap. The code is usually still stored even after the light goes out, so read it.

Do I need a scan tool for a 1995-2000 LS400?

Yes. The 1995 and later cars use OBD II, and you need a scan tool that can read the ABS module, not just engine codes.
