How to Replace Brake Rotors on an
Q50

By Core Brake Parts Tech Team — Circleville, OH warehouse

Figuring out how to replace brake rotors on an Infiniti Q50 is mostly a matter of adding two steps to a pad job: unbolting the caliper bracket from the knuckle, and separating the old rotor from the hub. Everything else, from lug nuts to bed-in, is the same work a pad change requires.

The steps that actually decide whether the job turns out well are freeing a rusted rotor without damaging anything and preparing the hub face properly. Both are covered below.

What you need on the bench

• Floor jack and jack stands. Never work under a vehicle supported only by the jack.
• Lug wrench, socket set, and a breaker bar for the caliper bracket bolts.
• C-clamp or a proper piston tool.
• Brake cleaner, high-temperature silicone caliper grease, and anti-seize for the hub face.
• Torque wrench, plus a hook or piece of wire to support the caliper.
• Penetrating oil and a hammer for stubborn rotors.

Step by step at each corner

1. Crack the lug nuts loose with the wheel still on the ground.
2. Lift the corner and lower it onto jack stands. Confirm it is stable before reaching underneath.
3. Remove the wheel and place it under the car as a backup.
4. Unbolt the caliper and hang it from a hook so the rubber hose carries none of its weight.
5. Unbolt the caliper bracket from the knuckle. This is the step that needs the breaker bar.
6. Pull the old rotor. It is usually held on by nothing more than rust or a small retaining screw, so remove the screw if one is fitted.
7. Free a stuck rotor with penetrating oil and taps around the hat, or by threading bolts into the two jacking holes many rotors provide and tightening them evenly.
8. Clean the hub face down to bare metal and apply a thin film of anti-seize.
9. Wipe the protective oil off the new rotor with brake cleaner, then fit it.
10. Reinstall the bracket and caliper at service-manual torque, with fresh grease on slide pins and contact points.
11. Refit the wheel and torque the lug nuts in a star pattern.
12. Pump the pedal until firm before moving the car.

The hub face is the difference between quiet brakes and a shudder

Rust or debris trapped under the rotor hat is a leading cause of thickness variation and pedal pulsation later. New rotors are machined flat, but they can only be as true as the surface they bolt against. A scaly hub tilts the disc slightly, and the resulting high spot grinds against the pads on every rotation until you can feel the variation through the pedal on a highway off-ramp. Take the hub down to clean metal with a wire wheel or hub cleaning disc and this problem simply does not appear.

Rear corners need a plan

On the Infiniti Q50 the rotors are light enough to handle easily, so physical effort is not the obstacle. The rear brakes are where a job can stall out. On many model years the rear pistons must be rotated in with a cube tool rather than pressed, because the parking brake mechanism runs through the piston on a thread. Forcing one back with a C-clamp risks ruining the caliper. Model years with an electronic parking brake need the system placed in service mode before the rear caliper will retract enough to accept new pads and a new rotor. Check your year's setup before the wheel comes off.

Pairing, torque, and bedding in

Replace rotors in axle pairs and always fit new pads with new rotors. Used pads have a transfer layer and wear pattern matched to the old disc, so putting them on a fresh rotor gives uneven contact and noise. Once both sides of the axle are done, bed in the new pads and rotors per the maker's procedure before any hard driving. That controlled sequence of stops lays an even transfer layer on the disc surface and is the single best thing you can do for long-term smoothness.

Torque values for the lug nuts, caliper bolts, and bracket bolts come from the service manual for your specific year. Do not guess them. Undertorqued caliper hardware can back out, and overtorqued fasteners can stretch or snap.

Frequently asked questions

How often do brake rotors need to be replaced?

There is no fixed interval. Rotor life depends on driving style, climate, and how promptly worn pads get replaced. Measure against the minimum thickness stamped on the rotor and inspect for scoring, cracks, and a heavy edge lip at every pad change.

Is it safe to drive with the caliper hanging from the hose?

You should never even let it hang while parked. A brake hose is not a support strap, and the internal damage from that kind of load is invisible until the hose fails. Use a hook or wire every time.

Do I need a scan tool for the rear brakes?

Only if your model year has an electronic parking brake, which requires service mode before the rear caliper will retract. Years with a conventional screw-type piston need a cube tool instead. Confirm which one applies to your car in advance.

What causes a new rotor to vibrate within a few thousand miles?

Most often a dirty hub face, skipped bed-in, or reused pads. All three lead to uneven material transfer or thickness variation. Cleaning the hub, fitting new pads, and following the bed-in procedure prevents nearly all of it.
