How to Replace Brake Pads on a Lexus ES 350

By Core Brake Parts Tech Team — Circleville, OH warehouse

Yes, a home mechanic can replace the brake pads on a Lexus ES 350. The front axle is a standard floating-caliper job that takes most DIYers one to two hours with basic hand tools, a floor jack, and jack stands. The rear axle takes a little longer on model years with an electronic parking brake, because the parking-brake motor has to be retracted before the piston will move.

Fresh pads and new hardware clips restore the quiet, smooth pedal the ES 350 is known for, and the job is well within reach if you follow the service manual for torque values.

Tools and Parts You Need

• Floor jack and a pair of jack stands rated for the vehicle
• Lug wrench or breaker bar with the correct socket
• Metric socket set and ratchet for the caliper slide bolts
• C-clamp or caliper piston compression tool (a cube-style rotating tool for rear pistons that screw in)
• Torque wrench that covers both the caliper bolt and lug nut ranges
• Brake cleaner and a wire brush
• High-temperature silicone caliper grease
• Wire hook or bungee to hang the caliper
• New brake pads for your Lexus ES 350, sold in axle sets
• A fresh brake hardware kit with abutment clips and pin boots
• Turkey baster or syringe for drawing down brake fluid if the reservoir is full

Step-by-Step: Replacing Front Brake Pads on a Lexus ES 350

1. Loosen the lug nuts. With the car on the ground and the parking brake set, break each lug nut loose about a quarter turn. Do not remove them yet.
2. Lift and support the car. Raise the front on the factory jack point with a floor jack, then set jack stands under the pinch welds or subframe. Lower the car onto the stands and give it a firm shove to confirm it is stable. Never work under a vehicle held only by a jack.
3. Remove the wheel. Spin off the lug nuts and pull the wheel. Set it flat under the rocker panel as a backup support.
4. Open the brake fluid reservoir. Pop the hood and remove the reservoir cap. If the fluid is at the MAX line, draw a little out so it does not overflow when you compress the pistons.
5. Unbolt the caliper. Remove the two slide bolts on the back of the caliper. Lift the caliper off the bracket and hang it from the strut spring with a hook so the rubber hose is never carrying the caliper's weight.
6. Remove the old pads and clips. Slide the pads out of the bracket and pull the stainless abutment clips. Note how the pads sit so the new ones go in the same orientation.
7. Inspect the rotor. Look for deep grooves, heat spots, or a lip at the outer edge. Measure the thickness with a micrometer and compare it to the minimum stamped on the rotor hat or listed in the service manual. If it is at or below minimum, replace the rotors now rather than putting new pads on a worn surface.
8. Compress the piston. Place an old pad against the piston and squeeze it back with a C-clamp or piston tool while watching the reservoir. Go slowly and stop if the fluid nears the top.
9. Clean and grease the slides. Pull the slide pins out of the bracket, wipe them clean, and coat them with silicone caliper grease. Replace torn pin boots. Wire-brush the pad landing areas on the bracket until the metal is clean.
10. Install new hardware and pads. Snap in the new abutment clips, put a thin film of grease on the clip contact points, and slide in the new pads.
11. Reinstall the caliper. Set the caliper over the pads, thread in the slide bolts by hand, and torque them to the spec in the Lexus service manual. If the manual calls for thread locker on the bolts, use it.
12. Fit the wheel. Run the lug nuts up by hand, lower the car, and torque the lugs in a star pattern to the manual's value.
13. Pump the pedal. Before moving the car, press the brake pedal several times until it is firm. The first stroke will go to the floor because the pistons are retracted. Top off the reservoir and replace the cap.
14. Bed in the pads. Follow the pad maker's bedding procedure, typically a series of moderate stops from speed without coming to a complete halt, then a cool-down drive.

Rear Brake Pads on the ES 350: Electronic Parking Brake Notes

The rear axle follows the same sequence with two differences. On model years equipped with an electronic parking brake, the parking-brake motor holds tension on the caliper. It must be placed in service mode through the vehicle's menu or with a scan tool that can retract the motor before the piston will compress. Forcing the piston against an engaged motor can damage the actuator.

On rear calipers where the parking brake works through the caliper piston, the piston does not press straight back. It must be rotated in with a cube tool that engages the notches in the piston face. Check which style your car uses before you start, and have the right tool on hand. After the pads are in, take the parking brake out of service mode and cycle it a few times so it self-adjusts.

Safety First

• Work on a level concrete surface and chock the wheels that stay on the ground.
• Never rely on the jack alone. Jack stands are mandatory.
• Wear safety glasses and nitrile gloves; brake dust and brake cleaner are both irritants.
• Do not let the caliper hang by its hose. A stressed hose can fail internally and cause a soft pedal later.
• Keep brake fluid off painted surfaces. It strips paint quickly.
• Always pump the pedal before driving. A car with retracted pistons has no brakes on the first press.

When to Call a Shop

Most ES 350 owners can handle this job, but stop and get help if you find a seized slide pin that will not come out, a caliper piston that will not retract even with the parking brake in service mode, brake fluid leaking around the piston seal, or a rotor that is cracked or heavily warped. Any of these means the caliper or rotor needs replacement, not just pads. If the pedal stays soft after pumping and topping off, the system may have air in it and needs a proper bleed. A shop can also handle the electronic parking-brake reset if you do not have a scan tool.

Frequently Asked Questions

How long does it take to replace brake pads on a Lexus ES 350?

Plan on one to two hours for the front axle if this is your first time, and a bit longer for the rear on cars with an electronic parking brake. Experienced DIYers usually finish an axle in under an hour.

Do I need to replace the rotors at the same time?

Only if they are below the minimum thickness, grooved, or showing heat damage. Measure them while the caliper is off. If they pass, new pads on a smooth rotor are fine. If they fail, replace them in pairs across the axle.

Why does my pedal go to the floor after the job?

Because the pistons were pushed back and have not yet returned to contact with the new pads. Pump the pedal several times with the car stopped until it firms up. If it stays soft, check for leaks and have the system bled.

Should I replace pads on one wheel or both?

Always in axle sets. Replacing pads on only one side gives uneven braking and can pull the car under hard stops.
