How to Replace Brake Pads on a Honda Ridgeline

By Core Brake Parts Tech Team — Circleville, OH warehouse

Yes, a home mechanic can replace the brake pads on a Honda Ridgeline. Plan on one to two hours per axle the first time, and expect the job to need a floor jack, a pair of jack stands, a socket set with a breaker bar, a caliper piston tool, and a torque wrench. The Ridgeline runs heavy-duty calipers and rotors, so the hardware is bigger and heavier than what you would find on a Civic, but the procedure follows the same familiar pattern.

Before you buy anything, confirm your lug count and your brake package. Ridgeline trims and tow packages use different pad and rotor sizes, and a pad set that fits one truck will not necessarily fit yours. The find-your-vehicle tool narrows the catalog to parts confirmed for your year and trim so you are not guessing at the parts counter.

Tools and Parts You Need

• Floor jack rated for the truck and two jack stands
• Lug wrench or impact with the correct socket
• Socket set, ratchet, and a breaker bar for the caliper bracket bolts
• C-clamp or caliper piston compression tool
• Wire hook or bungee cord to hang the caliper
• Brake cleaner and a stiff wire brush
• High-temperature silicone caliper grease
• Torque wrench that covers lug-nut and caliper-bolt ranges
• Micrometer or brake caliper gauge for rotor thickness
• New brake pads for your Ridgeline in an axle set
• Fresh abutment clips and slide-pin boots from a brake hardware kit

Step-by-Step: Replacing Ridgeline Brake Pads

1. Park on level concrete and chock the wheels. Set the transmission in Park. If you are working on the rear axle and the truck has an electronic parking brake, put the system into service mode per the owner's or service manual before you touch the rear calipers. Release a manual parking brake if the truck has one.
2. Loosen the lug nuts about a half turn while the tire is still on the ground. Trying to break them loose in the air just spins the wheel.
3. Lift and support the truck. Raise it with the floor jack at the factory lift point and set a jack stand under the frame or the designated support point. Lower the truck onto the stand. Never work under a vehicle held only by a jack.
4. Remove the wheel and set it flat under the truck as an extra safety backup.
5. Unbolt the caliper. On most Ridgeline setups, the two caliper slide bolts come out and the caliper body lifts off the bracket. The heavy-duty caliper is not light; hold it with one hand while you back out the last bolt so it does not drop and yank the brake hose.
6. Hang the caliper from the coil spring or a suspension arm with your hook. The hose must never carry the caliper's weight.
7. Pull the old pads and clips. Note which pad had the wear sensor and where any shims sat. Lay the old parts out in order so the new ones go back the same way.
8. Inspect and measure the rotor. Look for deep scoring, heat spots, and a heavy lip at the outer edge. Measure thickness with a micrometer and compare it to the minimum figure stamped on the rotor hat or listed in the service manual. A rotor at or under minimum gets replaced, not reused.
9. Compress the caliper piston. Open the master cylinder reservoir cap first and watch the fluid level as you push the piston back with the C-clamp or piston tool against an old pad. If the reservoir is near full, draw some fluid out with a clean syringe so it does not overflow onto the paint.
10. Clean the bracket and slide pins. Pull the pins, wipe off the old grease, and brush rust off the pad abutment surfaces. Any corrosion left under the clips will make the new pads bind and wear crooked.
11. Install new hardware. Snap the fresh abutment clips into the bracket, then coat the slide pins with silicone caliper grease and slide them back in with new boots if the old ones were torn.
12. Fit the new pads. Put a thin film of grease on the pad ears where they ride in the clips and on the backing plate where the piston and caliper fingers contact. Keep grease off the friction face.
13. Reinstall the caliper over the new pads and torque the slide bolts to the figure in the service manual. If the manual calls for thread locker on the bolts, use it; do not guess at torque values on caliper hardware.
14. Refit the wheel and snug the lugs, lower the truck, then torque the lug nuts in a star pattern to spec.
15. Pump the brake pedal until it is firm before you put the truck in gear. The first few strokes just move the pistons back out to the pads. Top off the reservoir and replace the cap.
16. Repeat on the other side of the axle, then take the truck out for the bed-in procedure the pad maker prints on the box.

Front Versus Rear on the Ridgeline

The front calipers do most of the work and are the ones owners replace first. The rear axle is where the surprises live. Newer Ridgelines use an electronic parking brake that clamps the rear caliper pistons; compressing those pistons without service mode can damage the actuator. Older trucks may carry rear drums instead of discs, a different job with shoes and springs rather than pads. Pull a rear wheel and look before you order parts.

Safety First

Brake work puts you under a heavy truck and around parts that were recently very hot. Use jack stands every time, keep a wheel under the frame as a backup, and let the brakes cool first. Wear safety glasses with brake cleaner or a wire brush, and never blow brake dust off with compressed air. Tighten every fastener with a torque wrench, and expect the pedal to go to the floor on the first stroke until the pistons reseat. Do not drive until the pedal is firm.

When to Call a Shop

Hand this job off if the rotor measures under minimum and you are not set up to replace it, if the caliper piston will not compress or the boot is torn and leaking, if a caliper bracket bolt is rounded off, or if the electronic parking brake will not enter service mode. A pedal that stays soft after pumping means air or a leak in the system, and that needs a proper bleed before the truck moves. Working through the full brake parts catalog lets you gather rotors, calipers, and hardware in one order if the inspection turns up more than worn pads.

Frequently Asked Questions

How long do Ridgeline brake pads last?

It depends on load, towing, and driving style. Trucks that tow regularly or spend their lives in stop-and-go traffic wear pads far faster than highway commuters. Measure the friction material any time the wheels are off rather than relying on a mileage figure.

Do I need to replace the rotors at the same time?

Not automatically. If the rotor is above minimum thickness and smooth, new pads can go on it. Replace it if it is scored, warped, heat-checked, or at the minimum spec, and always replace rotors in pairs across the axle.

Why do the trim and tow package matter for pads?

Honda fits larger brake hardware to some Ridgeline configurations, and those trucks use a different pad footprint. Ordering by year alone can land you the wrong set, so verify fitment by trim and package before you buy.

Can I reuse the old clips and pins?

You can, but you should not. Old clips lose their spring tension and trap rust, and old boots let water into the slide pins. A hardware kit is inexpensive insurance against noise and uneven wear.
