By Core Brake Parts Tech Team — Circleville, OH warehouse
You can replace the brake pads on a Ford Edge at home with ordinary hand tools in about an hour per axle. The front calipers are a conventional floating design that comes apart with two slide bolts, and the rear is nearly identical except that many model years require the electronic parking brake to be put in service mode before the piston will retract. A floor jack, jack stands, a socket set, a piston tool, and a torque wrench are the core of the kit.
The Edge is a midsize crossover with most of its weight over the front axle, so the front pads take the bulk of the braking load and wear first. Many owners do the fronts once between rear services. Either way, the procedure is the same as any modern floating-caliper vehicle, with the rear parking brake as the one wrinkle to plan for.
Tools and Parts You Need
- Floor jack and two jack stands
- Lug wrench or breaker bar
- Socket set with ratchet and extension
- C-clamp for front pistons; cube-style rotating tool for rear pistons that screw in
- Torque wrench
- Brake cleaner, shop rags, wire brush
- High-temperature silicone caliper grease
- Bungee cord or wire hook for hanging the caliper
- Micrometer or rotor gauge
- An axle set of Ford Edge brake pads
- Fresh abutment clips and pin boots from a brake hardware kit
- Rotors if the old ones are below minimum thickness or grooved
- Scan tool or dashboard procedure for parking-brake service mode when doing the rear
Preparation
Park on level pavement, put the transmission in Park, and chock the wheels on the axle that stays on the ground. Open the hood and note the brake fluid level. Pushing the pistons back raises the level, so if it is already at MAX, plan to remove a little fluid with a clean syringe. Loosen the reservoir cap so the fluid can move freely when you compress the pistons.
Step-by-Step: Front Axle
- Loosen the lug nuts a half turn while the tire is on the ground.
- Lift the corner at the factory jack point, set a jack stand under the frame rail or reinforced pinch weld, and lower the Edge onto the stand. Never work under a vehicle held only by a jack.
- Remove the wheel and lay it under the rocker as a backup.
- Remove the two caliper slide bolts. Lift the caliper off the bracket and hang it with a hook so the brake hose carries no weight.
- Slide the old pads out and pull the abutment clips from the bracket.
- Inspect the rotor. Look for deep scoring, a heavy outer lip, and heat discoloration. Measure thickness against the minimum on the hat and replace the rotor if it fails.
- Compress the piston with a C-clamp against an old pad, watching the reservoir level.
- Pull the slide pins, clean them, check the rubber boots, and apply a thin film of high-temperature silicone grease. Reinstall and confirm they glide.
- Clean the bracket channels with a wire brush and snap in the new clips.
- Install the new pads, wear indicator positioned like the originals.
- Reinstall the caliper and torque the slide bolts to the service-manual spec. Apply thread-locker only if the manual requires it.
- Refit the wheel, lower the vehicle, and torque the lugs in a star pattern per the service manual.
- Do the opposite side, then pump the pedal until it is firm.
Step-by-Step: Rear Axle and Electronic Parking Brake
- Before lifting the vehicle, put the electronic parking brake into service mode using a scan tool or the dashboard procedure in the service manual. Many Edge model years require this or the rear piston will not move.
- Lift, support, and remove the wheel as on the front.
- Unbolt and hang the caliper, then remove the pads and clips.
- Inspect and measure the rotor.
- Retract the piston. Some rear pistons press straight back; others must be rotated in with a cube tool that engages notches in the piston face. Match the tool to your caliper and never force a rotate-in piston with a C-clamp.
- Grease the pins, install new clips and pads, reinstall the caliper, and torque per the service manual.
- Refit the wheel and torque the lugs in a star pattern.
- Exit service mode, cycle the parking brake switch several times, and pump the pedal until firm.
| Rotor condition | Reuse or replace |
|---|---|
| Above minimum thickness, smooth surface | Reuse with new pads |
| Above minimum, light scoring you cannot catch a fingernail on | Reuse; new pads will seat to it |
| Deep grooves, heavy outer lip | Replace |
| Blue heat spots or pedal pulsation | Replace |
| At or below the minimum stamped on the hat | Replace, no exceptions |
Safety Reminders
- Jack stands every time, on solid ground, with the wheels chocked.
- Brake dust is abrasive; keep it wet with cleaner and out of your lungs.
- Brake fluid damages paint, so cap the reservoir and clean drips immediately.
- Replace pads in full axle sets. One new pad and one worn pad on the same axle pulls the vehicle under braking.
- Look up torque values. Never guess caliper-bolt or lug-nut torque.
- Confirm a firm pedal before backing out of the driveway.
Bedding In the Pads
Follow the bed-in procedure from the pad manufacturer. It usually consists of a series of moderate-speed slowdowns with cooling time between them and no hard, complete stops while the brakes are hot. That first heat cycle deposits an even friction layer on the rotor and is the difference between quiet brakes and a squeal that starts a week later.
When to Call a Shop
Bring the Edge to a shop if the parking brake will not enter service mode, if a piston is seized, if a brake hose is cracked or ballooned, or if the pedal stays soft after pumping. A soft pedal means air in the lines or a leak, both of which need a professional bleed and inspection. A seized slide bolt that strips or snaps in the bracket is another job better handled with a lift and the right extraction tools.
Frequently Asked Questions
How long does it take to replace Ford Edge brake pads?
About an hour per axle for a first-timer. The rear takes a bit longer because of the parking brake service mode step. All four corners fit comfortably in an afternoon.
Does the Ford Edge need a special tool for the rear brakes?
On years with an electronic parking brake, you need a scan tool or the dashboard procedure to enter service mode, and some rear pistons require a cube-style tool to rotate them in. Check the service manual for your year.
Can I do just the front pads?
Yes. Fronts wear faster on the Edge and are commonly replaced on their own. Always do both sides of an axle together.
Why is my pedal soft after the pad change?
The pistons need to take up the new clearance. Pump the pedal until it firms up. If it stays soft after several pumps, stop and check for leaks or air in the system.
