2017-2023 Honda Ridgeline Front vs Rear Brakes: What Wears First and What to Replace

By Core Brake Parts Tech Team — Circleville, OH warehouse

On a 2017-2023 Honda Ridgeline the front brakes almost always wear out first, because the front axle does most of the stopping work every time the truck slows down. The rear pads and rotors last longer, but they are not maintenance-free: they carry the parking brake, see extra load when you tow or haul, and should be checked every time the fronts are replaced. Here is how the system is laid out, how to tell which end needs attention, and what to buy for each.

How the Ridgeline's brakes are laid out

Honda's specification sheet for this generation lists power-assisted brakes with ventilated front discs and solid rear discs, backed by 4-wheel ABS, Electronic Brake-force Distribution (EBD) and Brake Assist. Every trim also gets Hill Start Assist and Honda's i-VTM4 all-wheel-drive system. There are no rear drums on this truck: it is four-wheel disc, with an internally vented rotor up front where the heat is greatest and a solid rotor at the rear.

The parking brake is not electronic. Both the 2017 and the 2023 owner's manuals describe a foot-operated parking brake pedal, and Honda warns that driving with it applied can damage the rear brakes and axle. The maintenance schedule includes a "check parking brake adjustment" item alongside "inspect front and rear brakes," which tells you the rear system has mechanical parts that need looking after, not just pads.

Why the front brakes wear first

When any vehicle brakes, its weight transfers toward the front tires. The front tires then have more grip, so the brake system is designed to send more of the clamping force there, and EBD adjusts the front-to-rear balance based on load and conditions. That is why Honda put the vented rotors on the front: they have to absorb and shed most of the heat.

The Ridgeline is also a heavy vehicle. Honda Canada lists curb weights of 2,015 to 2,054 kg (roughly 4,440 to 4,530 lb) depending on trim, with a gross vehicle weight rating of 2,730 kg. Every extra pound in the bed or cab adds to the energy the brakes turn into heat, and most of that heat goes into the front rotors.

When the rear brakes wear faster than expected

• Towing. The Ridgeline is rated to tow up to 5,000 lb and comes pre-wired for a trailer brake controller. Honda recommends trailer brakes for any trailer of 1,000 lb or more; if the trailer's own brakes are weak or missing, the truck's brakes do all the work.
• Heavy bed loads. Weight in the bed shifts more of the braking share rearward.
• A dragging parking brake. If the pedal is not fully released, or the parking brake is out of adjustment, the rear pads rub constantly. The owner's manual notes a beeper sounds when you start driving with the parking brake pedal not fully released; do not ignore it.
• Seized caliper slides. Rear calipers catch road salt and grime, so their guide pins are prone to sticking, which wears one pad (often the inner) far faster than the other.

Symptoms: which end is the problem?

Honda's quick-reference guide in the owner's manual says a screeching sound when you apply the brake pedal can mean the pads need replacement. Take that seriously: waiting until the squeal turns into grinding usually turns a pad job into a pad-and-rotor job.

A falling fluid level is also a clue. Brake fluid drops slowly as pads wear, because the caliper pistons move outward and hold more fluid. Honda's manual advises having the vehicle inspected for leaks or worn brake pads if the level reaches the MIN mark.

What to replace, front vs rear

Front brake job

Replace the front pads on both sides and, in most cases, both front rotors at the same time. The front rotors do the hardest work and are the ones that develop thickness variation and cause the steering-wheel shake. Wagner's service guidance is to measure each rotor for lateral runout, parallelism and minimum thickness against the manufacturer's specification before deciding to reuse it; the minimum thickness is marked on the rotor or listed in the factory service manual. Browse brake rotors and ceramic brake pads, which suit a daily-driven truck that sees the occasional trailer.

Rear brake job

The rear pads usually outlast the fronts, but measure them every time the front wheels are off. Solid rear rotors have less mass to absorb heat and rust readily on trucks that sit, so rear rotors are often replaced with the pads rather than reused. While you are there, check the parking brake adjustment, since that is part of Honda's scheduled inspection.

Doing both ends at once

If both axles are near the end of their life, or you tow regularly, a single front-and-rear job saves a second weekend and keeps friction material matched front to rear. We carry a 2017-2023 Honda Ridgeline front and rear brake kit with pads and rotors for both axles. For a single axle, start with our brake pads collection and filter by your truck.

What to do at the same time

• New hardware. Wagner points out that old hardware can be weakened and corroded, so fit new clips and attaching hardware. See brake hardware kits.
• Clean and lubricate the caliper slides. Wire-brush rust from the caliper brackets, use a high-temperature lubricant on metal-to-metal contact points and a silicone lubricant on rubber-to-metal points, per Wagner's checklist.
• Wash new rotors. Wagner advises washing all rotors, new ones included, with soap, hot water and a scrub brush to remove oils and fine particles.
• Brake fluid. Honda says to replace brake fluid every 3 years regardless of the Maintenance Minder, and specifies Honda Heavy Duty Brake Fluid DOT 3. DOT 5 is not compatible with the system. If the fluid is due, flush it at the same visit.
• Hoses and calipers. Look for cracked brake hoses and leaking or sticking calipers, especially at the rear where corrosion builds up.

How hard is the job, and breaking in new brakes

Pads and rotors on either axle are a reasonable job for a home mechanic with a floor jack, jack stands, a torque wrench and a caliper piston tool. Torque the caliper bracket bolts and lug nuts to the values in the factory service manual rather than guessing. The rear axle adds one step: make sure the parking brake is fully released before you try to pull the rotor, and verify that the parking brake holds before the truck goes back on the road.

Honda's owner's manual says to avoid hard braking for the first 200 miles after replacing brake pads or rotors so they can break in properly. Wagner's bedding guidance is a series of moderate stops from about 30 mph with cooling time between them. Either way, give new friction material a gentle start before you tow.

Frequently Asked Questions

Does the 2017-2023 Ridgeline have rear drum brakes?

No. Honda lists ventilated front discs and solid rear discs for this generation, so it has four-wheel disc brakes.

Does the Ridgeline have an electronic parking brake?

No. The 2017 and 2023 owner's manuals both describe a foot-operated parking brake pedal that you press to apply and press again to release.

Should I replace front and rear brakes at the same time?

Only if both are worn. Fronts usually wear first. Measure the rear pads and rotors at every front job and replace the rear set when it nears the minimum. If you tow often, doing both axles together keeps things simple.

Why are my rear pads worn more than my fronts?

Common causes are a parking brake that is not fully releasing or is out of adjustment, a sticking rear caliper slide, or frequent towing and heavy loads. Check the rear hardware and slides before installing new pads.

What brake fluid does the Ridgeline use?

Honda specifies Honda Heavy Duty Brake Fluid DOT 3 and says to replace it every 3 years. DOT 5 fluid is not compatible with the system.

Can I just replace the pads and keep the rotors?

Only if the rotors measure above minimum thickness and are within runout and parallelism specifications. Wagner notes that installing new pads on old rotors can reduce stopping power and wear the new pads early.

Sources

1. Honda Canada 2017 Ridgeline specifications - ventilated front/solid rear discs, ABS, EBD, Brake Assist, i-VTM4, 5,000 lb towing, curb weight and GVWR
2. 2023 Honda Ridgeline Owner's Manual - foot parking brake, DOT 3 fluid, 3-year fluid replacement, brake and parking brake inspection items, 200-mile break-in, trailer brakes
3. 2017 Honda Ridgeline Owner's Manual, brake system page - pedal-operated parking brake and rear brake damage warning
4. Wagner Brake disc brake service checklist - rotor measurement, rotor washing, lubrication, bedding
5. Wagner Brake pads and rotors pairing - new pads on old rotors, replacing old hardware
