On a 2017-2020 Genesis G80, most caliper trouble comes down to three things: slide or guide pins that stop moving freely, a piston that corrodes and sticks, or a fluid leak at the piston seal or banjo fitting. A dragging caliper shows up as a pull to one side, a hot smell or one wheel that is much hotter than the others after a drive. Before you buy a caliper, rule out the pins and hardware, and make sure the car has had the ABS module recall done, because that recall is often confused with a caliper problem.
How the G80 Caliper System Works
The G80 uses disc brakes at all four corners. Genesis's own brake service bulletin for the G80 and G90 (TSB 21-BR-002HG) gives separate procedures for two front caliper designs: a floating caliper that slides on lubricated pins, and a fixed caliper with pistons on both sides that stays put while the pads move on guide pins. The service steps are different for each, so check which one is on your car before ordering parts or starting work.
The rear calipers on the G80 work with an Electronic Parking Brake (EPB). The G80 quick reference guide lists an EPB warning light and an AUTO HOLD indicator in the cluster. That matters for caliper work: the rear piston is tied to an electric actuator for the parking brake, so you cannot just push it back with a C-clamp.
| Caliper type | How it moves | Common failure point | Service note from Genesis |
|---|---|---|---|
| Front floating | Slides on two pins | Dry, corroded or over-greased slide pins | Remove, clean and inspect pins and boots; apply the specified silicone paste lightly |
| Front fixed | Body stays still; pistons on both sides | Corroded guide pins and pad springs | Clean pins by a non-abrasive method; do not grease them unless the shop manual says to |
| Rear with EPB | Slides on pins, with an electric parking brake actuator | Seized pins, piston that will not retract | Release with Brake Pad Change Mode before removal; rotate the piston to retract |
Symptoms of a Bad Caliper on a G80
- Pulling to one side while braking or even while cruising, because one caliper is not releasing.
- A hot, burning smell after a drive, or one wheel that is much hotter to the touch than the others.
- Uneven pad wear, such as the inner pad worn far more than the outer pad on the same wheel. That points at pins or a sticking piston rather than normal wear.
- Wetness around the caliper or on the inside of the wheel, or a brake fluid level that keeps dropping.
- A soft or sinking pedal, which can come from a caliper seal leak or air in the system.
- Warning lights: the parking brake and brake fluid warning light, or the EPB warning light if a rear caliper actuator or its circuit has a problem.
Brembo's caliper guidance explains why these show up together: when slide pins deteriorate, you get sliding system blockage, residual drag, overheating of the rotor and early, abnormal wear of the pads and rotor. One bad caliper can take a set of pads and a rotor with it if it is ignored.
What Causes G80 Caliper Problems
Slide and guide pin issues
This is the most common cause and the cheapest fix. Genesis's bulletin makes a point most people miss: too much grease is as bad as too little. Over-lubricated slide pins can trap air at the end of the pin and create an "air spring" that pushes the caliper and pads back into the rotor, causing drag. On fixed front calipers, the bulletin says not to grease the guide pins at all unless the shop manual calls for it.
Corrosion and dust boot damage
Brembo notes that caliper parts deteriorate over time, especially from road salt and from chemical degreasers used to clean the vehicle. The dust boot keeps water and dirt away from the piston. Once a boot tears, moisture reaches the piston surface, it rusts, and the piston sticks in its bore.
Piston seal wear
The seal inside the caliper does more than hold fluid in. Per Brembo, it also pulls the piston back after each stop and lets it move out as the pads wear. A hardened or damaged seal can leak, or it can stop retracting the piston, which leaves the pad dragging.
Leaks at the banjo bolt
Not every wet caliper is a failed caliper. Genesis's bulletin says that if fluid is leaking where the brake hose meets the caliper at the banjo bolt, the fix is to replace the copper sealing washers on that fitting, not the caliper.
Is It Really Brake Fluid? A Test From Genesis
Calipers are assembled with an assembly lubricant, and some residue around the piston can be normal. Genesis's bulletin gives a simple test before you condemn a caliper:
- Collect a sample from the piston area with a cotton swab, without disturbing the caliper boot.
- Draw a few horizontal lines on paper with an ink pen.
- Wipe the sample down across the lines.
- If the ink does not smear, it is most likely assembly oil; wipe it off. If the ink runs or smears, it is likely brake fluid, and you need to find and fix the leak.
The ABS Module Recall Is Not a Caliper Problem
Genesis recalled certain 2017-2020 G80 vehicles under NHTSA campaign 21V-160 (Genesis recall 006G). The Anti-Lock Brake System module can malfunction internally and cause an electrical short, which could lead to an engine compartment fire while parked or driving. The owner letter advised parking outside and away from structures until the remedy is done, and seeing a Genesis retailer promptly if the Malfunction Indicator Light is on. This is an electrical issue in the ABS unit, not the calipers, and the recall remedy is free. Run your VIN through the NHTSA recall lookup before any brake work so you are not chasing an ABS fault with caliper parts.
Replacing a G80 Caliper: What to Replace Together
If the pins are seized, the piston is stuck, or the caliper is leaking at the seal, replace the caliper. Replace them in pairs across the axle so both sides clamp the same. When one caliper has been dragging, check the pads and rotor on that wheel: heat from a dragging caliper often glazes pads and damages the rotor surface.
- Calipers: loaded or bare, matched to your front type (floating or fixed). Browse replacement brake calipers.
- Pads: fresh pads with new shims. Genesis says never reuse shims on new pads and always use the retainers or springs that come with the new pads. For the front, see our 2017-2020 Genesis G80 front ceramic brake pads.
- Rotors: if the rotor is below the minimum thickness in the shop manual, scored, or heat-damaged. See brake rotors.
- Hardware: pad retainers, anti-rattle springs and pin boots from a brake hardware kit.
- Hose washers or hoses: new copper washers on the banjo fitting, and a new brake hose if the old one is cracked or swollen.
- Brake fluid: a bleed is required after any caliper swap. Use the DOT fluid type your shop manual or reservoir cap specifies.
How Hard Is the Job?
A front caliper swap on a G80 is a moderate DIY job for someone who has done brakes before. You need to bleed the brakes afterward, and Genesis stresses keeping the reservoir from dropping below halfway between MIN and MAX while bleeding, or air gets into the system and you have to start over.
The rear is harder because of the EPB. Genesis's procedure is to put the system in Brake Pad Change Mode with a scan tool to release the rear calipers, unplug the EPB actuator before removing the caliper, retract the piston by rotating it, then cycle the EPB apply and release three times and run the Assembly Check function after replacing rear pads, a caliper or the actuator. Without a scan tool that supports the G80's EPB functions, the rear is a job for a shop.
Torque every caliper bolt, bracket bolt and bleeder to the values in the factory service manual, tighten the lug nuts in a star pattern, and bed in new pads and rotors with a series of moderate stops before normal driving.
Need the part? Shop Brake Calipers at Core Brake Parts
Filter by your exact year, make, and model — every part ships from our Circleville, OH warehouse, free over $75.
Shop Brake Calipers →Frequently Asked Questions
Can I rebuild my G80 caliper instead of replacing it?
Yes, if the bore and piston are not pitted. Rebuild kits with new seals, boots and pins exist, but if the piston or bore is rusted, a replacement caliper is the more reliable fix and usually less labor.
Why is only one wheel on my G80 hot after driving?
That wheel's caliper is most likely not releasing fully, from a stuck piston, seized pins, or over-greased pins trapping air. Check the pins first; if they move freely, the piston or seal is the likely cause.
Do I need a scan tool for the rear calipers?
For a proper job, yes. The G80 has an Electronic Parking Brake, and Genesis's procedure uses Brake Pad Change Mode to release the rear calipers and an Assembly Check function after replacing rear pads or a caliper.
Is the 2017-2020 G80 ABS recall related to the calipers?
No. Recall 21V-160 covers an internal electrical short in the ABS module that can cause a fire. It is repaired free by a Genesis retailer and does not involve the calipers.
Should I replace calipers in pairs?
Yes. Replacing both sides of the axle keeps braking force even and prevents a pull. A single new caliper next to a worn one can make the car pull under braking.
There is oil around my caliper's piston. Is it leaking?
Maybe not. Use Genesis's ink smear test: if the fluid does not smear ink, it is assembly oil and can be wiped off. If it smears, it is brake fluid and the leak needs to be found.
