EBC Brakes for the Ford Bronco: Which Parts Fit

EBC brake pad compounds for the Ford Bronco

By Core Brake Parts Tech Team — Circleville, OH warehouse

EBC makes pads for every current Bronco, but the right part number depends on which Bronco you have. The standard 2021-and-newer Bronco and the Bronco Raptor use different front brakes, the Bronco Sport is a separate vehicle with its own pads, and the 1994-1996 full-size Bronco is a different truck again. Match the part to your exact model and engine first, then pick the EBC compound that suits how you drive.

Four Broncos, Four Different Brake Setups

The Bronco name covers vehicles that share almost no brake parts. Ford's own spec sheets show how far apart the current models are, and those numbers are the reason one pad number will not fit them all.

Model Front rotor (dia. x thickness) Front caliper Rear rotor Rear caliper
Bronco 4x4 (6th gen) 311 x 34 mm vented, cast iron Floating, dual 51 mm pistons 308 x 24 mm, high carbon cast iron Floating, single 54 mm piston
Bronco Raptor 350 x 34 mm vented, Nitro Tough Iron Floating, dual 51 mm pistons 336 x 20 mm, Nitro Tough Iron Floating, single piston
Bronco Sport 308 x 27 mm vented Single piston 302 x 11 mm disc Single piston, electric park function

Ford lists the 6th-generation Bronco with power vented disc brakes, ABS, electronically controlled brake boost and automatic emergency braking, offered with the 2.3L EcoBoost four-cylinder, the 2.7L EcoBoost V6 and, in the Raptor, the 3.0L EcoBoost V6. The Raptor's front rotor is 39 mm larger in diameter than the standard truck's, so its pads are a different shape. The Bronco Sport is a different vehicle underneath and uses an electric brake booster and rear calipers with electric parking function, so nothing from the full-size Bronco crosses over to it.

The older 1994-1996 Bronco (the last of the original full-size run) uses its own front rotor, so parts for that truck are listed separately and never fit the modern models.

EBC Parts We Carry That Fit the Bronco

These are the EBC parts in our catalog listed for the Bronco family. Each listing names the model and engine it fits, so read that line before you order.

2021 and newer Bronco (standard models)

Bronco Raptor

Bronco Sport

1994-1996 Bronco

If you want a non-EBC option for the modern truck's rear axle, we also carry Baer drilled and slotted rear rotors for the 2021-2026 Bronco. For everything else, browse our full brake pad collection and brake rotor collection.

Extra Duty vs Yellowstuff vs Greenstuff: Which Compound

EBC sells three truck compounds for the Bronco, and they are built for different jobs.

Compound Best for What EBC says about it
Extra Duty Towing, heavy loads, lifted trucks on big tires Carbon granule compound with aramid fiber and minimal steel fiber, rotor friendly, minimal dust, bed-in over the first several hundred miles
Yellowstuff Maximum stopping power, spirited driving, towing High-friction aramid fiber compound with strong cold bite and fade resistance; not a low-dust pad
Greenstuff Daily highway driving with a step up from stock Medium dust, cleaner than stock, very low rotor wear, better resistance to dust and sand

Extra Duty is the pick for a Bronco that has been lifted and put on oversize tires, or one that tows. EBC designs it specifically for trucks towing, carrying heavy loads, or running lifted suspension and oversized tires, and EBC describes it as extremely rotor friendly. It needs a longer bed-in than the others: EBC calls for normal driving for the first 600 to 800 miles, then about 15 medium to heavy stops to finish curing the surface.

Yellowstuff gives the most bite. EBC rates its truck Yellowstuff at an average friction coefficient of 0.5 and says it works from cold, which makes it the right choice when bigger tires have made the stock brakes feel marginal and you want the pedal to bite hard right away. The trade-off is dust: EBC is clear this is not a low-dust pad.

Greenstuff is the gentle upgrade. EBC describes it as a highway pad for light trucks and SUVs with a medium dust factor, cleaner running than stock, and very low rotor wear. For a Bronco that is mostly a daily driver with the occasional trail day, it is the easiest pad to live with.

Signs Your Bronco Brakes Need Attention

Bigger tires are the most common reason Bronco owners start shopping for pads. A larger, heavier tire takes more force to slow, so a truck that stopped well from the factory can feel soft after a tire upgrade. Watch for these signs:

  • Longer stops or a pedal that needs more push after a lift or tire upgrade, or while towing.
  • Squealing or grinding, which usually means the pads are worn to the wear indicator or down to the backing plate.
  • Vibration through the pedal or steering wheel under braking, often from uneven pad deposits or rotor thickness variation.
  • Brake fade on long downhill grades, when the pedal goes soft after repeated stops and returns once the brakes cool.
  • Heavy grit and mud buildup after off-road use, which can wear pads unevenly and cause noise.

If the pedal sinks to the floor, the brake warning light stays on, or the truck pulls hard to one side, stop driving it and have the hydraulic system inspected. Those are not pad problems.

What to Replace at the Same Time

Measure the rotors before new pads go on. If they are below the minimum thickness cast into the rotor, cracked, heavily grooved or warped, replace them; new pads on a worn rotor will not bed in evenly. On the 1994-1996 truck, the GD7045 slotted rotors listed above are a direct replacement for the front

Also replace the pad hardware and abutment clips if they are corroded or bent, clean and lubricate the caliper slide pins, and check the brake fluid condition. Our brake hardware kits cover the clips and pins. Always replace pads in axle sets, both sides at once.

How Hard Is the Job

A front or rear pad swap on a Bronco is a moderate driveway job with basic hand tools, a jack, stands and a caliper piston tool. Two points deserve care on the newer trucks:

  • Check the rear parking brake type first. Ford lists the Bronco Sport's rear calipers with electric park function. On any caliper with an electrically actuated parking brake, the piston must be retracted using the service mode in the owner or service information, or a scan tool, before thicker new pads will fit. Forcing it back with a clamp can damage the actuator. Confirm how your truck's parking brake works in the service information before you start on the rear.
  • Torque values. Tighten the caliper bracket bolts, caliper bolts and lug nuts to the values in the factory service manual, and re-check the lug nuts after the first short drive.

After the job, follow the bed-in procedure for the compound you bought. For Extra Duty that means the long break-in EBC describes above; Yellowstuff and Greenstuff carry a red brake-in coating that EBC says allows safe braking right after installation, but they still benefit from a set of moderate stops before hard use.

The parts that fix this — verified to fit your Ford Bronco Which Parts

Shop the part →or see all Ford Bronco Which Parts brake parts

Ships from our Circleville, OH warehouse. Free shipping over $75.

Frequently Asked Questions

Do Bronco Raptor pads fit a regular Bronco?

No. Ford lists the Raptor with a 350 mm front rotor against 311 mm on the standard Bronco 4x4, so the front pads are a different shape. Use the Raptor-specific part number for a Raptor and the standard part for every other 6th-generation trim.

Will Bronco Sport brake pads fit a full-size Bronco?

No. The Bronco Sport is built on a different platform with smaller single-piston brakes, a 308 mm front rotor and a 302 mm rear rotor. Its pads fit only the Bronco Sport.

Which EBC pad is best for a lifted Bronco on 35-inch tires?

Extra Duty is EBC's pad built for lifted trucks on oversized tires and for towing. If you want the strongest possible bite and do not mind more dust, Yellowstuff is the alternative.

Do I need new rotors with new EBC pads?

Only if the rotors are below minimum thickness, cracked, deeply grooved or causing vibration. Otherwise the rotor surface should be cleaned of old pad material so the new compound can bed in evenly.

Are EBC Yellowstuff pads dusty?

Yes, more than a low-dust pad. EBC says Yellowstuff is not a low-dust compound; if clean wheels matter most, Greenstuff runs cleaner than stock.

Sources

  1. Ford: 2025 Bronco Technical Specifications - Bronco 4x4 and Raptor rotor sizes, caliper types, brake system description, engines
  2. Ford: 2025 Bronco Sport Technical Specifications - Bronco Sport rotor sizes, electric park function, electric booster
  3. EBC Brakes: Extra Duty Truck and SUV Pads - compound, towing and lifted-truck use, bed-in procedure
  4. EBC Brakes: Yellowstuff Truck Sport Pads - friction level, cold bite, dust characteristics
  5. EBC Brakes: Greenstuff Truck and SUV Pads - highway use, medium dust, low rotor wear
