2011-2020 Dodge Durango Brake Caliper Problems and Replacement

By Core Brake Parts Tech Team — Circleville, OH warehouse

Caliper trouble on a 2011-2020 Dodge Durango almost always shows up as one of three things: the SUV pulls to one side under braking, one wheel runs hot and smells after a drive, or the inner pad on one corner wears out far ahead of the outer pad. The usual cause is a sticking piston or seized slide pins, not a cracked caliper, and the fix is a replacement caliper (ideally as a pair on the axle) with new pads, fresh hardware and a proper bleed. If your Durango is a 2015 or 2016, check one recall first, because it covers the left front caliper itself.

How the Durango's calipers work

The third-generation (WD) Durango shares its brake architecture with the WK2 Jeep Grand Cherokee, which is why so many Durango brake parts are listed for both vehicles. On standard-brake Durangos, the front caliper is a floating design: the caliper housing rides on two slide bolts threaded into a caliper adapter (the bracket), and hydraulic pressure pushes the pistons out against the inner pad while the housing slides inward to pull the outer pad against the rotor. FCA's own service procedure for the 2015-2016 front caliper describes pushing the caliper pistons back into the housing, removing a tension clip, and unbolting two slide bolts under dust covers, which is the layout you will see when you pull the front wheel on standard-brake models.

The SRT is different. Dodge's launch material for the 2018 Durango SRT lists Brembo six-piston front and four-piston rear calipers over vented rotors of 15 inches (front, slotted) and 13.8 inches (rear). Those are fixed, opposed-piston calipers: the housing does not slide, so there are no slide pins to seize, and service is about pistons, seals and pads. Parts for the SRT are not interchangeable with standard-brake Durangos, so confirm which system you have before ordering.

The 2015-2016 left front caliper recall

NHTSA campaign 16V-168 (Chrysler recall S16) covers 2015-2016 Dodge Durango and Jeep Grand Cherokee models with four-wheel anti-lock disc brakes built from December 9, 2015 through January 13, 2016. FCA stated that the left front caliper housing on about 22,800 vehicles may have been cast from the wrong material and could rupture under extreme brake application, which would lengthen stopping distance.

The dealer check is simple: the tech cleans the date-code pad cast into the left front caliper housing and reads it. A housing stamped 3405, or one where the code is unreadable, gets a new caliper at no charge. If you own a 2015 or 2016 Durango and are replacing calipers anyway, run your VIN through the NHTSA recall lookup first. If the recall is open, the dealer does the left front for free, and you can decide on the rest from there.

Symptoms of a failing Durango caliper

• Pull to one side when braking. A caliper that cannot apply or release evenly gives unequal force side to side, and the SUV veers toward the dragging corner.
• One hot wheel, burning smell, heavy dust on one wheel. A piston that will not retract keeps the pads rubbing. After a drive, carefully compare the heat coming off each wheel by holding a hand near (not on) it; one much hotter than the other points to that caliper.
• Uneven pad wear. An inner pad worn far thinner than the outer on the same corner is the classic sign of a floating caliper that no longer slides.
• Fluid on the inside of the wheel or tire. A leaking piston seal or banjo bolt washer leaves wet brake fluid on the caliper and inner rim. Treat this as urgent.
• Soft or long pedal, longer stops. Air or fluid loss at a caliper, or a caliper that cannot clamp fully, shows up as a pedal that travels farther.
• Clunk or knock when braking. Loose slide bolts or a missing caliper clip let the housing shift in the bracket.

What causes Durango calipers to stick

Most caliper problems on these SUVs come from corrosion and age, not defects. Brake and Front End's technical coverage explains that a piston seal loses flexibility as it ages or becomes contaminated, so the piston no longer returns to its rest position and the brakes drag. A torn piston boot lets water reach the bore, which rusts the piston surface and makes the drag worse.

On floating calipers, the other big cause is the slide hardware. Seized or corroded slide bolts, dried-out guide boots, a rusted bracket where the pad ears sit, or the wrong grease on the pins all keep the housing from centering. The result is the inner pad doing all the work. If only the slides are the problem and the piston moves freely and does not leak, cleaning the bracket and pins and relubricating with a high-temperature brake lubricant can cure it. Once a piston is sticking, a seal is weeping, or the boot is torn, the caliper should be replaced or rebuilt.

Replacing a Durango caliper: what the job involves

On standard-brake Durangos, a front caliper swap is a driveway job for someone who has done pads before. FCA's recall procedure for the 2015-2016 left front caliper outlines the sequence:

1. Remove a small amount of fluid from the master cylinder reservoir so it does not overflow when you push the pistons back, and keep fluid off painted surfaces.
2. Lift the vehicle, remove the wheel, and push the caliper pistons into the housing.
3. Remove the caliper tension clip, the slide bolt dust covers and the two slide bolts.
4. Remove the brake hose banjo bolt and discard the old copper washers.
5. Lift the caliper off the adapter, move the pads over to the new caliper as needed, and mount it.
6. Torque the slide bolts to 41 ft. lbs. (55 N-m), then reinstall the dust covers.
7. Reconnect the hose with new copper washers and the original banjo bolt at 23 ft. lbs. (30 N-m), confirming the hose is not twisted or kinked.
8. Bleed the brakes, install the wheel and tighten the lug nuts to 100 ft. lbs. (136 N-m).

Those torque figures come from FCA's 2015-2016 recall instructions for the standard front caliper. For rear calipers, SRT Brembo calipers or other model years, use the values in the factory service manual for your exact vehicle. FCA's parts list for that recall calls for DOT 3 brake fluid; check the cap on your master cylinder reservoir to confirm the fluid your Durango takes before topping up or bleeding.

Power Stop's caliper installation guidance adds the steps that keep a new caliper from failing early: clean the bracket with a brass brush and brake cleaner, fit new abutment clips if the old ones are rusted, grease the guide pins and pad contact points with high-temperature lubricant, use new crush washers at the hose where required, and bleed per the service manual so debris does not clog the new caliper.

What to replace with the caliper

Replace calipers in pairs. Power Stop recommends replacing calipers as a front pair or rear pair so both sides apply with the same force and the SUV does not pull. A new caliper on one side and a decade-old one on the other rarely brakes evenly.

Pads and usually rotors. A dragging caliper overheats the pads and often glazes or scores the rotor on that corner. Pads contaminated with brake fluid must be replaced. If the rotor is scored, heat-spotted or below its minimum thickness, replace rotors as a pair too. Our front Z17 ceramic brake kit for the 2011-2020 Durango and Grand Cherokee bundles matched pads and rotors for that job, and you can browse more Durango-compatible brake pads and replacement brake rotors.

Hardware and hoses. New slide pin boots, abutment clips and copper washers are cheap insurance. Check the rubber brake hose while you are there; a hose that has deteriorated inside can hold pressure on a caliper and mimic a stuck piston. See our brake hardware kits and brake hoses.

The caliper itself. Replacement calipers for standard-brake Durangos are in our brake calipers collection, with Cardone and Power Stop options.

How hard is the job?

For a standard-brake Durango, a front or rear caliper pair is moderate difficulty: basic hand tools, a torque wrench, a piston compressor, jack stands and a way to bleed the brakes. The step people skip is bleeding. Opening the hose at the caliper lets air in, and a Durango with air in the lines will have a soft pedal. If your SUV has a soft pedal after a caliper job, bleed again before blaming the new part. SRT Brembo calipers are more involved because of their piston count and cost, and many owners leave those to a shop.

Frequently Asked Questions

Is my 2015 or 2016 Durango covered by the caliper recall?

Only if it falls in the build window of December 9, 2015 through January 13, 2016 and the recall has not already been done. Enter your VIN on NHTSA's recall lookup or ask a Dodge dealer. The inspection reads the date code on the left front caliper housing, and the fix is free.

Do I need to replace both front calipers if only one is sticking?

It is strongly recommended. Replacing calipers in pairs keeps clamping force equal side to side, so the Durango stops straight and wears pads evenly.

Can I just clean and lube the slide pins instead?

Yes, if the piston moves freely, the boot is intact and there is no fluid leak. Clean the pins and bracket, replace the pin boots and use high-temperature brake lubricant. If the piston is sticking or leaking, replace the caliper.

Are SRT calipers the same as a regular Durango's?

No. The 2018 and later Durango SRT uses Brembo six-piston front and four-piston rear fixed calipers with larger rotors. Standard-brake calipers, pads and rotors do not fit an SRT, and SRT parts do not fit a standard Durango.

Why does my Durango pull after replacing one caliper?

The most common reasons are air in the system, a sticking caliper or slide pins on the opposite side, or a failing brake hose. Bleed the system and inspect the other side; this is the main argument for replacing calipers in pairs.

What brake fluid does a Durango caliper job need?

FCA's recall procedure for the 2015-2016 Durango specifies DOT 3 brake fluid. Always confirm against the marking on your master cylinder reservoir cap and use fresh fluid from a sealed container.

Sources

1. FCA Dealer Service Instructions, Safety Recall S16 / NHTSA 16V-168 - affected vehicles and build dates, about 22,800 units, date code 3405, replacement steps, slide bolt, banjo bolt and lug nut torque, DOT 3 fluid
2. NHTSA recall data, 2016 Dodge Durango - recall 16V168 component, summary and free dealer remedy
3. Stellantis Media, 2018 Dodge Durango SRT release - Brembo six-piston front and four-piston rear calipers, 15-inch and 13.8-inch rotors
4. Brake and Front End, Brake Caliper Diagnostics - piston seal aging, boot damage and seized hardware as causes of drag and pad wear
5. Power Stop, When Should I Replace Brake Calipers - failure symptoms and replacing calipers in pairs
6. Power Stop, Brake Caliper Installation Tips - bracket cleaning, lubrication, new crush washers and bleeding
