On a 2013-2018 Cadillac ATS, replace the rotors if they are at or below the minimum thickness cast or stamped on the rotor, cracked, heat-spotted, or deeply scored. Resurfacing only makes sense for a rotor with plenty of thickness left that has a measured pulsation or scoring problem. GM's own guidance says routine pad replacement, squeal and cosmetic rust are not reasons to machine a rotor at all.
How the ATS brake system is built
GM's new-model service information for the ATS lists standard four-wheel disc brakes with ventilated rotors, four-channel ABS and an Auto Dry brake feature. Some cars got the optional Brembo four-piston front calipers. All ATS disc rotors were made using GM's Ferritic Nitro-Carburizing (FNC) corrosion protection process. FNC is a surface treatment, so cutting the rotor on a lathe removes the treated layer on the friction faces. Keep that in mind before you send a lightly worn ATS rotor out for machining.
The same document says the electric parking brake (EPB) came with the Tremec 6-speed manual or the Driver Assist Package (RPO Y66). If your car has the EPB, the rear brake job takes an extra step: the parking brake has to be put in service mode with a scan tool or the procedure in the service manual before the rear caliper pistons can be retracted. Do not force the pistons back on an EPB caliper.
Because ATS trims used different brake packages (base calipers, Brembo front calipers, and the separate ATS-V system), rotors are not interchangeable across every car. Match the rotor to your trim and brake package, or check the rotor diameter on the car before you order.
Resurface or replace: the decision on an ATS
Start by measuring. Use an outside micrometer and check thickness at several points around each rotor, about mid-way across the pad contact area. Record the lowest reading and compare it to the minimum thickness marked on the rotor. GM's bulletin says the minimum is stamped on the backside of the rotor, and that you should confirm in the service information whether the stamped number is the minimum after refinishing or the discard spec. Brembo's maintenance guidance lists rotor thickness at or below the manufacturer's minimum as the first reason to replace a rotor.
| What you find | Do this | Why |
|---|---|---|
| Thickness at or below the stamped minimum | Replace | Brembo and GM both treat this as the hard limit |
| Cracks, blue or dark heat spots, deep circular grooves | Replace | Brembo lists all of these as replacement criteria |
| Pedal pulsation, rotor well above minimum | Measure runout, then resurface on a calibrated lathe or replace | GM ties pulsation to thickness variation from runout or corrosion and calls for refinishing |
| Scoring deeper than 1.5 mm (0.060 in) | Resurface if it stays above minimum after the cut, otherwise replace | GM's bulletin threshold for severe scoring |
| Light surface rust, discoloration or hard spots, squeal, routine pad change | Reuse as-is | GM says rotors should not be refinished or replaced for these |
In practice, many ATS owners land on replacement. A rotor that has already been through one set of pads often does not have enough material to cut and still stay above minimum for the life of the next set. A cut also strips the FNC layer, so the faces can rust faster afterward. New rotors with fresh pads are usually the cleaner job.
Pulsation: what is actually wrong
A pulsing pedal is the most common reason people ask about rotors, and it is usually not a "warped" rotor. GM's disc brake service bulletin (00-05-22-002N, which covers 2014 and prior GM cars, including the early ATS) explains that pulsation comes from rotor thickness variation. The uneven rotor pushes the caliper piston in and out, and you feel that pumping through the pedal.
Thickness variation usually starts with lateral runout (LRO). GM's spec is 0.050 mm (0.002 in) or less of LRO on the assembled brake corner. Above that, the pads wear the rotor unevenly and thickness variation builds over time. GM notes runout-driven pulsation usually develops 3,000 to 10,000 miles after the cause, so owners rarely connect it to the service that started it. Uneven lug nut torque after a tire rotation or brake inspection is a common trigger, and GM says impact wrenches on wheel nuts greatly raise the odds. The other cause is corrosion from a car that sat for long periods in humid conditions.
That means a pulsation fix that only swaps rotors can come back if the hub face is rusty or the wheel is torqued unevenly. Clean the hub, check runout with a dial indicator, and torque the wheel properly.
Doing the job right
- Clean the hub face. GM says cleaning every mating surface between hub, rotor and wheel so it is free of corrosion, burrs and debris is critical, whether you machine or not.
- Do not machine new rotors. GM states new rotor surfaces are already ground for a smooth finish and parallel faces. Its bulletin is blunt: do not refinish new rotors.
- Clean and lubricate the hardware. Service caliper slide pins and pad contact points, and replace worn clips. A brake hardware kit is cheap insurance.
- Check runout. GM mounts a dial indicator to the knuckle with the tip about 6.35 mm (0.25 in) in from the rotor's outer edge, then rotates the rotor to find the low and high points.
- Torque the wheels correctly. GM calls the star-pattern torque sequence critical and says to use a torque wrench or torque stick. Use the lug nut value in your owner's manual or service manual, not an impact gun at full tilt.
- Bed in the pads. Brembo says bedding lasts about 300 km (roughly 186 miles). Use moderate, gradual stops and avoid hard braking that can overheat new pads and rotors.
What to replace together
New rotors call for fresh friction. Putting old, glazed pads on new rotors gives poor contact and can cause noise. If you are replacing rotors on one axle, put new brake pads on that axle too. GM's bulletin says rotors do not have to be replaced in pairs, but it warns that a different surface finish side to side can cause a pull. Most techs do rotors in axle pairs for that reason.
If you are doing both ends, a matched kit keeps it simple. We carry the 2013-2018 Cadillac ATS (base brakes) front and rear brake kit, which is built for cars with the base brake package. Brembo-equipped and ATS-V cars use different parts, so confirm your package first. You can also browse our brake rotors and ceramic brake pads by vehicle.
While you are in there, look at the brake fluid and the flexible hoses. Swollen or cracked hoses and old fluid both affect pedal feel, and a new rotor will not fix either.
How hard is the job
Front rotors on an ATS are a straightforward driveway job for someone who has done brakes before: caliper off, bracket off, rotor off, clean the hub, reassemble and torque. Hanging the caliper by its hose is the classic mistake. Support it with a wire or hook instead. The rear is the same, plus the EPB service-mode step if your car has an electric parking brake. If you do not have a scan tool or a confirmed manual release procedure for your car, that is the point where a shop earns its labor.
The parts that fix this — verified to fit your Cadillac ATS
- 2013-2018 Cadillac ATS (base brakes) Front and Rear Brake Kit - Callahan — $321.99
- 2013-2019 Cadillac ATS Front & Rear Brake Kit - Detroit Axle — $285.99
- Front & Rear Ceramic Brake Pads Set for Cadillac ATS W/Standard Brakes 2013-2019 — $70.99
Ships from our Circleville, OH warehouse. Free shipping over $75.
Frequently Asked Questions
Can I resurface the rotors on my Cadillac ATS?
Yes, if they stay above the stamped minimum thickness after the cut and the reason is measured pulsation or deep scoring. Machining removes the FNC anti-corrosion layer, and a thin rotor may not have enough material left, so replacement is often the better choice.
Do I have to replace ATS rotors every time I change pads?
No. GM says resurfacing during normal pad replacement is not needed. If the rotors are above minimum thickness, smooth, and free of cracks, heat spots and pulsation, new pads can go on the existing rotors.
Why does my ATS steering wheel or pedal shake when braking?
Usually thickness variation in the front rotors, which GM links to lateral runout, hub corrosion or uneven lug nut torque. Measure runout and thickness variation before deciding to cut or replace.
Where is the minimum thickness on an ATS rotor?
It is cast or stamped on the rotor, usually on the hat or outer edge. The service manual for your car also lists it. Always measure at the thinnest point.
Do Brembo-equipped ATS cars use the same rotors as the base car?
Not necessarily. The ATS was offered with base brakes and optional Brembo front calipers, and the ATS-V has its own system. Match parts to your trim and brake package or measure the rotor before ordering.
Do I need a scan tool for rear brakes on an ATS?
Only if the car has the electric parking brake, which came with the 6-speed manual or the Driver Assist Package. The EPB must be put in service mode before the rear pistons can be pushed back.
Sources
- GM 2013 Cadillac ATS new model features service information (NHTSA) - ventilated four-wheel discs, Auto Dry, optional Brembo 4-piston front calipers, FNC rotors, EPB availability
- GM Bulletin 00-05-22-002N, Disc Brake Warranty Service and Procedures (NHTSA) - measuring and minimum thickness, when to refinish or not, LRO spec and check, pulsation causes and mileage, scoring depth, pairs, no refinishing new rotors, torque
- Brembo - Indications and bedding in - rotor replacement criteria and bedding-in distance
