BMW 5 Series F10 G30 Brake Guide

By Core Brake Parts Tech Team — Circleville, OH warehouse

Short answer: The BMW 5 Series F10 and G30 use 5x120 five-bolt wheels, internally vented front rotors from about 330mm on the 528i/530i up to 374mm on the 550i, and an electronic parking brake. Both require a new single-use wear sensor with every pad set. This guide walks through the exact diagnostic steps, replacement thresholds, product comparisons, and cost breakdown so you can decide with confidence whether to DIY or take it to a shop.

Direct experience note: we ship these parts daily from our Circleville, OH warehouse to customers across the country. The picks in this guide reflect what fits, what lasts, and what our repeat-buyer mechanics come back for.

What to Know About Bmw 5 Series Brake Replacement

Understanding BMW 5 series brake replacement matters because it directly affects stopping distance, brake pedal feel, and how often you replace consumables. Getting it right the first time saves both money and follow-up shop visits.

• The F10 (2010-2017) and G30 (2017-2023) 5 Series both use a 5x120 bolt pattern secured with five wheel bolts, not lug nuts.
• All variants run internally vented front rotors; sizes climb from roughly 330mm on the 528i/530i to about 374mm on the 550i and M550i.
• Rear rotors run roughly 330-345mm and are vented on most trims, but confirm vented-versus-solid on your specific engine and trim.
• Both generations use a button-operated electronic parking brake with no hand lever: the F10 typically uses drum-in-hat shoes while the G30 uses motor-on-caliper actuators.
• Torque wheel bolts to about 120 Nm (89 ft-lb); G30 rear pad service requires placing the electric parking brake in maintenance mode before retracting the piston.
• BMW electronic wear sensors are single-use wire loops, usually one front and one rear mounted diagonally, tied to the Condition Based Service system.

Spec Chart by Vehicle Class

How to Diagnose or Replace

1. Loosen the wheel bolts, lift the car, secure it on stands, then remove the road wheel.
2. For the G30, activate parking-brake service mode via iDrive or a scan tool before touching the rear caliper.
3. Unclip and disconnect the electronic pad wear sensor from the affected caliper.
4. Remove the caliper guide-pin bolts, lift off the caliper, and support it without straining the hose.
5. Slide out the old pads, then compress or wind back the piston to seat the new pads.
6. Replace rotors if scored or below minimum thickness, and always fit a new wear sensor.
7. Reassemble, torque the wheel bolts to spec, pump the pedal firm, and release service mode.

Once diagnosis is complete, order the exact replacement parts for your vehicle - fitment matters. Related BMW 5 series brake replacement products are listed in the next section.

Recommended Parts and Where to Buy

Every product below is in stock at our Circleville, OH warehouse and ships same-day when ordered before 2 PM Eastern. Free shipping on orders over $75.

• Brake Pads
• Brake Rotors
• Bosch
• Brake Parts

If your exact vehicle is not listed, use the site search or filter the full brake parts collection by year and make.

Cost Breakdown - DIY vs Shop

DIY savings scale with vehicle size and job complexity. A full-size truck brake job saves $450-700 in labor. For most passenger cars, plan on 90-120 minutes per axle for pads only, 2-3 hours for pads plus rotors.

Install Tips - Where Most DIYers Go Wrong

• On the G30, place the electric parking brake in service mode before pushing the rear piston, or you can damage the actuator motor.
• Fit a fresh wear sensor with every pad set; the old loop is often already cut and will keep the brake warning on.
• After the job, reset the Condition Based Service brake counter in iDrive so the maintenance reminder tracks correctly.

Frequently Asked Questions

What's the short answer on BMW 5 series brake replacement?

The BMW 5 Series F10 and G30 use 5x120 five-bolt wheels, internally vented front rotors from about 330mm on the 528i/530i up to 374mm on the 550i, and an electronic parking brake. Both require a new single-use wear sensor with every pad set.

How much does BMW 5 series brake replacement cost?

It depends on your vehicle and how much you replace. For example, front pads only runs about $50-$130 parts in parts for a DIY job, or $200-$400 installed at a shop with labor included. The full cost breakdown is in the table above.

What should I check first?

Key things to check: The F10 (2010-2017) and G30 (2017-2023) 5 Series both use a 5x120 bolt pattern secured with five wheel bolts, not lug nuts; All variants run internally vented front rotors; sizes climb from roughly 330mm on the 528i/530i to about 374mm on the 550i and M550i.

Can I do this job myself?

Many DIYers can with basic tools. The first steps are: Loosen the wheel bolts, lift the car, secure it on stands, then remove the road wheel; For the G30, activate parking-brake service mode via iDrive or a scan tool before touching the rear caliper; Unclip and disconnect the electronic pad wear sensor from the affected caliper. The complete step-by-step is above.

Key Takeaways

• The BMW 5 Series F10 and G30 use 5x120 five-bolt wheels, internally vented front rotors from about 330mm on the 528i/530i up to 374mm on the 550i, and an electronic parking brake. Both require a new single-use wear sensor with every pad set.
• Measure friction material and rotor thickness at every tire rotation - catches wear before it becomes damage.
• Replace pads at 3 mm; below 2 mm is unsafe.
• Loaded calipers (with brackets, pads, and hoses) save 1-1.5 hours of labor per side over bare calipers.
• Bed new pads properly with 8-10 medium stops from 40 to 10 mph.
• Free shipping on orders over $75; same-day shipping on in-stock orders before 2 PM Eastern.
