2022-2023 Ford Maverick Brake Job Guide: Symptoms, Costs and the Right Parts

By Core Brake Parts Tech Team — Circleville, OH warehouse

A brake job on a 2022-2023 Ford Maverick means pads and, usually, rotors on a truck that has disc brakes at all four corners - Ford lists 4-wheel disc brakes with ABS on both the 2.5L hybrid and the 2.0L EcoBoost. The front axle does most of the stopping and wears first; the rear axle is a separate job that needs the electric parking brake put into its service mode before the caliper pistons can go back. Here is what wears, how to tell it is due, and what to buy together.

How the Maverick's Brakes Are Built

Every 2022-2023 Maverick uses the same basic layout: hydraulic disc brakes front and rear, ABS, and an electric parking brake worked by a switch on the center console instead of a lever or pedal. What changes between trucks is the powertrain and how much work the friction brakes actually do.

Ford rates every version for 1,500 lb of payload. Those numbers matter for brakes: a Maverick loaded to the bed rails or pulling a 4,000 lb trailer puts far more heat into its pads and rotors than the same truck commuting empty.

The hybrid adds regenerative braking. The owner's manual explains that the transmission captures braking energy and stores it in the high-voltage battery, and the cluster shows when regen alone is slowing the truck and when the conventional brakes are joining in. Because regen does part of the slowing, hybrid pads usually see less work than EcoBoost pads. The trade-off is that lightly used rotors can build surface rust and uneven deposits, especially on trucks that sit or live where roads are salted.

Symptoms That a Brake Job Is Due

• Grinding or a continuous squeal. Ford's own manual says occasional brake noise is normal, but a metal-to-metal grind or a squeal that does not stop means the linings may be worn out. A steady squeal is often the pad wear indicator doing its job - check the pads before the backing plate reaches the rotor.
• Vibration or shudder while braking. Ford flags continuous vibration or shudder in the steering wheel under braking as something to have checked. On the front axle this is usually rotor thickness variation; a shudder you feel in the seat rather than the wheel points more toward the rear.
• Red brake warning lamp while driving. With the parking brake released, Ford says this indicates low brake fluid or a brake system fault. Low fluid on a sealed system usually means the pads are thin (the caliper pistons have moved out) or there is a leak - check both.
• Heavy dust, pulling or a soft pedal. Some dust is normal. A pull to one side can mean a sticking caliper slide pin or piston. A soft or sinking pedal is a hydraulic problem, not a pad problem.
• Rusty rotor faces on a hybrid. If the outer band of the rotor is scaled and the pad only contacts part of the face, braking feels grabby or noisy even when the pads still have material.

Ford's maintenance schedule calls for inspecting the pads, rotors, linings, hoses and parking brake at every oil change interval, so a service visit is the easiest time to measure what is left.

Front vs Rear: What Wears and in What Order

Like any front-engine truck, the Maverick's front brakes carry most of the stopping load and wear out first. On a typical Maverick you will do front pads, often with rotors, before the rears need anything. Towing, mountain driving and a loaded bed shift more work to the rear axle and shorten both intervals.

The rear job is where the Maverick differs from an older pickup. Because the rear calipers carry the electric parking brake, you cannot simply push the pistons back with a clamp. The system has a dedicated mode for this: the manual describes the "Park Brake Maintenance Mode" message as a special mode used to allow service of the rear brakes. With the mode active, the parking brake mechanism backs off so the piston can be retracted and the new pads fitted. Forcing a piston back without it can damage the motor-on-caliper actuator. Also note that the electric parking brake will not operate with a dead 12V battery, so do the work with a healthy battery or a maintainer connected.

The Right Parts and What to Replace Together

For most Maverick owners the job comes down to three choices.

1. Pads only. Fine when the rotors are smooth, above minimum thickness and have no pulsation. Pick a ceramic compound for a daily driver: quiet, low dust and easy on rotors. Browse our ceramic brake pads or the full brake pad lineup.
2. Pads and rotors (per axle). The right call if there is pulsation, deep scoring, a lip at the rotor edge, rust-scaled faces or thickness near the minimum cast into the rotor. New rotors avoid the cost and uncertainty of machining thin factory rotors. See our brake rotors.
3. Towing-grade kit. If you run the 4K Tow Package, haul heavy or drive mountain grades, a severe-duty pad such as Power Stop's Z36 Truck and Tow carbon-fiber ceramic compound, paired with rotors built to shed heat, holds up better than a commuter pad. Power Stop kits include the pads, rotors, hardware and lubricant in one box - see the Power Stop collection.

Always replace or service at the same time:

• Abutment clips and hardware. Worn or rusty clips cause noise and uneven pad wear. Most quality pad sets include new ones; if not, add a brake hardware kit.
• Slide pin lubrication. Clean and re-grease the caliper pins with a high-temperature brake lubricant. A dry pin is the most common cause of one pad wearing faster than the other.
• Both sides of the axle. Pads and rotors are always replaced in axle sets so the truck stops straight.

Replace a caliper only when it leaks, the piston is seized or the boot is torn. If one front pad is worn far more than its partner, inspect that caliper before assuming pads alone will fix it.

Brake Fluid and the ABS Recall

Ford recommends DOT 4 Low Viscosity (LV) High Performance Brake Fluid meeting specification WSS-M6C65-A2, such as Motorcraft DOT 4 LV, and schedules a brake fluid change every 3 years regardless of mileage. The manual explains why: brake fluid absorbs water over time, which degrades braking performance. Low-viscosity fluid matters on this truck because the ABS and stability systems move it through small valve passages; use the specified fluid rather than a generic bottle.

A brake job is also a good time to confirm recall work. Under NHTSA recall 22V-730, Ford recalled 11,098 2022 Mavericks built from February 11, 2021 to September 5, 2022 because the ABS module could send an incorrect signal to the integrated trailer relay module and light the brake lamps when the brakes were not applied. The remedy is an ABS module software update at the dealer. A follow-up campaign, 25V-124, covers a small number of 2022 trucks whose earlier software update was not completed correctly. Neither affects pads or rotors, but brake lamps that stay lit with your foot off the pedal on a 2022 truck point to this recall rather than a worn pedal switch.

How Hard Is the Job?

Front pads and rotors on a Maverick are a straightforward job for a home mechanic with a jack, stands, a torque wrench and basic hand tools: remove the caliper, the caliper bracket and the rotor, then reassemble with the new parts. Torque every fastener to the values in the factory service manual - never guess on caliper bracket bolts. The rear axle adds the parking brake service mode step, and some owners hand that side to a shop or use a scan tool that can command the rear calipers open.

What drives the price of a Maverick brake job is predictable: pads only costs least, pads plus rotors on one axle costs more in parts but little extra in labor, and doing both axles roughly doubles both. Towing-grade kits cost more than commuter pads. Fluid service adds labor and fluid, but it is due every 3 years anyway, so pairing it with a brake job saves a separate visit. After any pad or rotor change, bed the new pads in with a series of moderate stops from speed so they lay an even layer of friction material onto the rotors.

Frequently Asked Questions

Does the 2022-2023 Ford Maverick have rear disc brakes or drums?

Ford's official specifications list 4-wheel disc brakes with ABS for both the 2.5L hybrid and the 2.0L EcoBoost, so the Maverick uses rear discs. Always confirm parts against your exact truck before ordering.

How do I retract the rear caliper pistons on a Maverick?

Put the electric parking brake into its maintenance mode first. The manual describes Park Brake Maintenance Mode as the special mode used to allow service of the rear brakes. With it active, the piston can be pushed back; without it, you risk damaging the parking brake actuator.

Do hybrid Maverick brakes last longer than EcoBoost brakes?

Generally yes, because regenerative braking does part of the slowing and the friction brakes do less work. Hybrid rotors can still need replacement from rust and uneven deposits when the brakes are used lightly, so inspect the rotors, not just the pads.

What brake fluid does the Maverick use?

Ford recommends DOT 4 LV High Performance Brake Fluid meeting WSS-M6C65-A2, such as Motorcraft DOT 4 LV, changed every 3 years.

Should I upgrade brakes if I tow with my Maverick?

If you tow near the 4,000 lb rating of the 4K Tow Package or drive long grades loaded, a severe-duty ceramic pad and matching rotors resist fade better than a daily-driver pad. For light, occasional towing, quality OE-style pads and rotors are enough.

Why do my brake lights stay on when I am not braking?

On a 2022 Maverick this matches NHTSA recall 22V-730, an ABS module software issue. Have a Ford dealer check the VIN for open recalls; the fix is a free software update.

Sources

1. Ford: 2022 Ford Maverick Technical Specifications - 4-wheel disc brakes with ABS on both powertrains, regenerative braking on the hybrid, curb weights, payload and towing ratings
2. Ford: 2022 Maverick Owner's Manual - Park Brake Maintenance Mode, electric parking brake operation, brake noise and vibration guidance, DOT 4 LV WSS-M6C65-A2 fluid, 3-year fluid change, inspection at each oil change
3. NHTSA: Part 573 Safety Recall Report 22V-730 - ABS module signal lights brake lamps; 11,098 2022 Mavericks; production dates and remedy
4. The BRAKE Report: Ford Recalls Maverick for Brake Light Issue - follow-up campaign 25V-124 for incomplete ABS software updates
5. Power Stop: Z36 Truck and Tow Brake Upgrade Kit - carbon-fiber ceramic severe-duty pads, drilled and slotted rotors, hardware and lubricant for towing and hauling
