When the ABS warning light stays on in a 2017-2019 Genesis G90, the car's anti-lock system has found a fault and switched itself off, but your normal power brakes still work. The most common causes are a wheel speed sensor or its wiring, a damaged sensor ring at a hub, low battery voltage, mismatched tire sizes, or low brake fluid. If the ABS light and the red Parking Brake and Brake Fluid light come on together, treat it as urgent: Genesis says the brake system may not work normally.

How the ABS System Works on the G90

The G90 has a wheel speed sensor at each corner. Each one reads a toothed ring or magnetic encoder that turns with the hub and sends a pulse signal whose frequency rises with wheel speed. The ABS control unit compares all four signals continuously. When one wheel slows much faster than the others under braking, the unit pulses hydraulic pressure to that caliper so the tire keeps rolling and you can still steer.

The same wheel speed signals feed Electronic Brake Force Distribution (EBD), which balances front-to-rear braking, and Electronic Stability Control (ESC). That is why one bad sensor can switch on several lights at once. The 2019 G90 owner's manual notes that when the ABS light is on, the speedometer, odometer or trip meter may not work and the steering-assist (MDPS) warning may come on, because those systems depend on the same data.

At start-up, the ABS light comes on for about 3 seconds while the system runs a self-check, then goes out. A light that stays on after that, or comes on while driving, means the system has stored a fault.

What the Warning Lights Mean

Common Causes of an ABS Light on a 2017-2019 G90

1. Wheel speed sensor or wiring fault

This is the usual cause. The sensors sit behind the wheels, where they are exposed to water, road salt, heat and brake dust. Brake and Front End, a trade publication for technicians, reports that most wheel speed sensor problems come from broken wires or loose or corroded connectors, not from the sensor itself. The harness that runs to each knuckle flexes with every suspension movement and can crack or rub through over time.

2. Debris, a damaged ring, or a worn hub bearing

Metal particles from worn brakes can collect on a magnetic sensor tip, and rust or a chipped tooth on the sensor ring gives the module an erratic signal. A loose or worn wheel bearing lets the gap between sensor and ring change as the wheel turns, which also upsets the signal. If you hear a hum from one corner that changes with speed along with an ABS light, check that hub.

3. Low battery voltage

Genesis states that after a jump start from a drained battery, the ABS light may come on because of low voltage, and that this does not mean the ABS has failed. Charge the battery fully, then restart. A weak battery or a poor ground on a car with as many electronic modules as the G90 can set several warning lights at once.

4. Long ABS activation on ice or snow

The manual also says that braking continuously on a slippery road keeps ABS active and can turn the warning light on. The fix is to pull over, shut the engine off and restart. If the light goes out, the system is normal.

5. Mismatched wheels or tires

A different tire diameter at one corner makes that wheel turn at a different speed, and the module can read it as a fault. The G90 manual warns that wheel and tire sizes different from original equipment may cause the ESC system to malfunction and says all four wheels and tires should match the original size. A mixed set of replacement tires or a badly underinflated tire can trigger it.

6. Low brake fluid

Low fluid by itself turns on the red Parking Brake and Brake Fluid light. Fluid drops slowly as pads wear, because the caliper pistons move out, but a sudden drop means a leak. If you see that red light together with the ABS light, the manual treats it as an EBD fault; do not keep driving.

7. ABS control unit, fuse or relay

The hydraulic unit and its electronic module can fail, and a blown fuse or bad connection at the module will switch the whole system off. This is the least common cause and the most expensive, so rule out the sensors, wiring, battery and tires first.

How to Diagnose It

1. Check the basics. Confirm the battery is healthy and fully charged, all four tires are the same size and set to the pressure on the door placard, and the fluid in the reservoir sits between MIN and MAX.
2. Read the codes. A basic engine code reader usually cannot see ABS codes. You need a scan tool that reads the ABS module. The code tells you which wheel and whether the problem is the circuit or the signal.
3. Watch live wheel speeds. Drive slowly with the scan tool connected and watch all four wheel speeds. Brake and Front End notes that many systems set a plausibility code when one sensor reads a few mph different from vehicle speed. A reading that drops out or jumps points to that corner.
4. Inspect the corner. Pull the wheel, check the harness and connector for damage and corrosion, clean the sensor tip, and check the hub for bearing play.
5. Clear and road test. After a repair, clear the codes and drive. Some faults only re-set after the car reaches a certain speed, so drive long enough to confirm the light stays off.

The Fix and What to Replace at the Same Time

Match the repair to the diagnosis. A wiring fault gets a harness repair or a new sensor with a new pigtail. A failed sensor gets a new sensor, installed with the connector fully seated and the harness clipped back in its original route so it cannot rub on a moving part. A worn bearing with a built-in sensor ring means a new hub assembly.

Because you will already have the wheel off and are working next to the caliper, it is a good time to look at the brakes themselves:

• Pads. The G90 has audible wear indicators: a high-pitched squeal from the front or rear when the pads are low. Genesis says to replace pads as complete front or rear axle sets. Our 2017-2019 Genesis G90 front ceramic brake pads are a full axle set, and you can browse more in our brake pads collection.
• Rotors. Check for scoring, heat spots and run-out. Rust flakes and metal dust from a worn rotor are the same debris that can collect on a sensor tip. See our brake rotors.
• Fluid. Genesis specifies brake fluid meeting FMVSS 116 DOT 3 or DOT 4. Old, wet fluid is hard on the ABS hydraulic unit, so if the fluid is dark, have it flushed with a scan tool that can run the ABS bleed routine.
• Hardware and hoses. Look at the flexible hoses for cracks while you are there. Our brake parts collection covers hardware, hoses and lines.

How Hard Is the Job?

Checking the battery, tires and fluid needs no tools. Reading ABS codes needs a scan tool that talks to the ABS module; many shops can do this quickly. Replacing a wheel speed sensor is a moderate driveway job on most corners: wheel off, unplug, remove the retaining bolt, clean the bore and install the new one. Rusted sensors can seize in the knuckle and break on removal, which turns a short job into a long one. A hub or ABS module replacement is a shop job for most owners, and an ABS module usually needs a scan-tool bleed afterward.

Until it is fixed, leave more following distance and brake gently on wet or icy roads, since the wheels can lock under a hard stop without ABS.

Frequently Asked Questions

Is it safe to drive my G90 with the ABS light on?

If only the ABS light is on, Genesis says your normal power brakes still work, but the anti-lock function does not. Drive carefully and have it checked soon. If the red brake light is on too, do not drive it; Genesis says the brakes may not work normally.

Can new brake pads turn on the ABS light?

Pads do not connect to the ABS system, but the work can. A sensor harness pulled out of its clips, a connector knocked loose, or a sensor bumped during caliper removal can set a code. Check the wiring at the corner you worked on.

Why did my ABS light come on after a jump start?

The G90 manual explains that low battery voltage can turn the ABS light on after a jump start without an actual ABS failure. Fully charge the battery and restart; if the light stays on, read the codes.

What brake fluid does the 2017-2019 G90 use?

The owner's manual specifies brake fluid meeting FMVSS 116 DOT 3 or DOT 4. Do not add any other type of fluid.

Why did my speedometer stop working when the ABS light came on?

Genesis notes that when the ABS light is on, the speedometer, odometer or trip meter may not work, because they rely on the same speed data. That points strongly at a wheel speed sensor or its wiring.

Is there a recall for ABS problems on the 2017-2019 G90?

When we checked NHTSA's recall database for this article, the 2017-2019 G90 recalls listed covered the turbocharger oil feed pipe, the starter solenoid and windshield bonding, not the ABS. Always run your own VIN on NHTSA's site, since new recalls can be added.
