2015-2019 Ford Edge Front vs Rear Brakes: What Wears First and What to Replace

By Core Brake Parts Tech Team — Circleville, OH warehouse

On a 2015-2019 Ford Edge, the front brake pads and rotors almost always wear out before the rears, because the front axle does most of the stopping. The rear brakes last longer, but they carry the electric parking brake, and on 2015-2018 models the rear brake hoses are under a federal safety recall. So when you check the rears, look at more than pad thickness.

How the Edge splits braking between front and rear

The second-generation Edge (2015-2019) has disc brakes at all four corners. It is built on a front-wheel-drive platform, with all-wheel drive as an option. Like nearly every road vehicle, it is set up with front brake bias. Summit Racing's technical help center defines brake bias as the percentage of total braking force sent to the front wheels. It lists 60-70% as common for rear-drive street vehicles and up to 80% for front-drive cars. The Motorist Assurance Program puts the front share at about 70% for a typical vehicle.

The reason is weight transfer. When you brake, the vehicle's weight pitches forward onto the front tires. They get more grip, so the system sends them more force. The rear brakes get a smaller share so the rear tires do not lock first and destabilize the vehicle. As a result, the front pads and rotors on an Edge turn more of its motion into heat and wear through friction material faster.

What wears first, and the signs to watch for

On a normally driven Edge, expect to replace the front pads first, often more than once before the rears need them. That is normal. How fast any Edge wears its brakes depends on how it is driven. The Motorist Assurance Program notes that frequent hard braking, aggressive driving and heavy loads all speed up wear. Hilly terrain, towing and short-trip city driving are hardest on the front axle.

Signs that the front brakes need attention:

• High-pitched squeal on light braking that goes away with firm pedal pressure. This is usually the pad wear indicator touching the rotor.
• Grinding or scraping. The friction material is gone and the backing plate is cutting into the rotor. Stop driving on it. The rotors will need replacing, not just resurfacing.
• Steering-wheel shake or pedal pulsation when braking from highway speed. This is typically uneven rotor thickness or pad material deposits on the front rotors.
• Pulling to one side. Look for a sticking caliper slide pin or a seized piston on the side the vehicle pulls toward.

Rear-brake problems on an Edge show up differently. Worn rear pads can squeal or grind like fronts. The rear axle also carries two systems the front does not. The first is the electric parking brake: a flashing brake warning lamp after you set the parking brake means the system needs service, according to Ford's owner information. The second is the rear brake hoses covered by the recall described below.

The rear brake hose recall on 2015-2018 Edge

If you own a 2015-2018 Edge, check this before you buy rear brake parts. In August 2025, Ford filed Part 573 Safety Recall Report 25V544 with NHTSA (Ford recall number 25S87). It covers rear brake jounce hoses on 414,717 Edge vehicles built from June 25, 2014 through December 21, 2017, plus 84,412 Lincoln MKX vehicles. That is 499,129 vehicles in total.

According to the recall report, the hoses can rupture prematurely and cause a progressive brake fluid leak. The driver may notice longer pedal travel and longer stopping distances. The red brake fluid warning light comes on if the reservoir level drops far enough. Ford states the root cause had not been fully determined. It saw far fewer repairs after the hose braid material was changed from polyvinyl alcohol to polyethylene terephthalate in December 2017. Affected vehicles were not built in VIN order, so the report tells owners to confirm their vehicle with a Ford or Lincoln dealer or Ford's customer line.

What this means for a brake job: if the pedal is soft or sinking, or the fluid level keeps dropping on a 2015-2018 Edge, suspect the rear hoses before you blame pads or the master cylinder. Have the recall status checked. Recall work is done at the dealer at no charge. When you have the rear wheels off anyway, look at both rear hoses for wetness, swelling or cracking.

Replacing front brakes on the Edge

The front job is a conventional pad-and-rotor service with no electronics involved:

1. Loosen the lug nuts, raise the vehicle on a lift or a jack, and support it on jack stands. Never work under a vehicle held up only by a jack.
2. Remove the caliper, hang it from the suspension so it does not hang by its hose, and remove the pads and caliper bracket to reach the rotor.
3. Measure the rotor against the minimum thickness cast or stamped on it. Replace it if it is under spec, heavily grooved, or has caused a pulsation.
4. Clean the bracket abutments, fit new pad hardware, and lubricate the slide pins with brake-specific grease.
5. Push the piston back and reassemble. Torque every fastener to the value in the factory service manual, including the lug nuts in a star pattern.
6. Pump the pedal until it is firm before you drive, then bed the new pads in with a series of moderate stops.

Front brake parts for this generation are in our 2015-2019 Ford Edge front ceramic brake pads and the wider brake rotor collection. Replacing pads and rotors together is the most reliable way to fix a pulsation complaint.

Replacing rear brakes: the electric parking brake step

The rear job is mechanically similar, with one step that is not optional: put the electric parking brake into maintenance (service) mode before you retract the rear caliper pistons. The parking brake is applied at the rear calipers by an electric actuator. If you force a piston back while the actuator is engaged, or unplug and reconnect it carelessly, you can damage the actuator, set fault codes, or end up with a parking brake that will not release. The switch-and-pedal sequence that enters maintenance mode is in the owner and service information for your model year. A scan tool that supports the Ford electric parking brake can also do it. Exit maintenance mode after reassembly and confirm the parking brake applies and releases.

Ford's owner information adds two practical points. The electric parking brake cannot be applied or released with a low or dead battery, so make sure the battery is healthy before you start. Various motor noises during apply and release are normal.

While the rear wheels are off, inspect the rear hoses for the recall concern above. Rear pads and rotors are in our brake pad collection and the Power Stop collection. Fresh brake hardware kits help new rear pads slide freely and wear evenly.

What to replace at the same time, and brake fluid

• Rotors with pads on the same axle. New pads on worn or uneven rotors are the most common cause of comebacks for noise and vibration.
• Both sides of an axle. Always replace pads and rotors in axle sets, never one wheel.
• Hardware and slide-pin boots. They are inexpensive and prevent pads from hanging up.
• Brake fluid. For the 2016 Edge, Ford specifies Motorcraft DOT 4 Low Viscosity (LV) High Performance brake fluid, PM-20, meeting WSS-M6C65-A2. Its owner information warns that other fluids may degrade brake performance. Top up or flush with fluid that meets that specification, not generic DOT 3.

Doing front and rear together is reasonable if the rears are close to their limit. On most Edges, though, the fronts come due alone, and a rear inspection is all the back axle needs at that visit.

Frequently Asked Questions

Why are my Edge's front brakes worn out while the rears still look good?

That is the normal pattern. The Edge's brake system sends most of the stopping force to the front axle because weight shifts forward when you brake, so the front pads and rotors wear faster.

Do I need a scan tool to do the rear brakes on a 2015-2019 Edge?

Not necessarily. The electric parking brake has to be put into maintenance mode before you retract the rear pistons. On many Ford vehicles you can do this with the parking brake switch and pedal sequence in the service information, or with a compatible scan tool.

Is my Edge covered by the rear brake hose recall?

NHTSA recall 25V544 (Ford 25S87) covers 2015-2018 Edge vehicles built between June 25, 2014 and December 21, 2017. They were not built in VIN order, so have a Ford dealer or Ford's customer line confirm your specific vehicle.

My brake pedal goes lower than it used to. Is it just worn pads?

Worn pads rarely cause a sinking pedal on their own. On a 2015-2018 Edge, a soft pedal with a dropping fluid level or a red brake warning light points to a leak. The rear jounce hoses in the recall are a known cause. Have it inspected before you drive further.

What brake fluid does the Edge use?

Ford specifies Motorcraft DOT 4 Low Viscosity (LV) High Performance brake fluid, PM-20, meeting WSS-M6C65-A2, for the 2016 Edge. Use fluid that meets that specification.

Sources

1. NHTSA Part 573 Safety Recall Report 25V544 - rear brake jounce hose recall scope, build dates, vehicle counts, symptoms and cause
2. Ford 2016 Edge Owner Manual - Electric Parking Brake - parking brake operation, low-battery limitation, warning lamp behavior
3. Ford 2016 Edge Owner Manual - Capacities and Specifications - DOT 4 LV brake fluid PM-20, WSS-M6C65-A2
4. Summit Racing Help Center - What is brake bias? - definition of brake bias and typical front-bias percentages
5. Motorist Assurance Program - Which Brakes Go Bad First, Front or Back? - front brakes handle about 70% of braking force; wear factors
