2012-2019 Nissan Versa Front vs Rear Brakes: What Wears First and What to Replace

By Core Brake Parts Tech Team — Circleville, OH warehouse

On a 2012-2019 Nissan Versa sedan or Versa Note, the front brakes wear out first, and usually by a wide margin. The fronts are disc brakes with pads that do most of the stopping; the rears are drum brakes with shoes that do far less work. Most owners replace front pads (and often rotors) several times before the rear shoes ever need attention.

This guide explains how the Versa's brakes are laid out, why the front end wears faster, how to tell which end is making the noise, and exactly what to replace at each end so the job only has to be done once.

How the Versa's Brake System Is Laid Out

Nissan's own owner's manuals for this generation spell out the layout. The 2015 and 2019 Versa Sedan manuals and the 2015 Versa Note manual all describe the same arrangement: front disc-type brakes that self-adjust every time the brake pedal is applied, and rear drum-type brakes that self-adjust every time the parking brake is applied. The parking brake is a hand lever that works the rear shoes.

Both ends share one hydraulic system, one master cylinder and one ABS unit. Nissan fits ABS with brake assist on these cars, and the ABS runs a self-test each time you start and drive off, which can cause a brief clunk or pedal pulse that is normal. The 2012 model year also still sold the older-generation Versa hatchback alongside the new sedan, so confirm your body style and generation by VIN before ordering parts for a 2012.

Why the Front Brakes Wear Out First

When any car brakes, weight shifts forward. That increases grip at the front tires and reduces it at the rear, so brake systems are engineered to put most of the braking force on the front axle. Summit Racing's technical help notes that front-wheel-drive cars can run a front bias as high as 80 percent. The Versa is a front-wheel-drive car with the engine and transaxle sitting over the front wheels, so the front brakes carry the bulk of every stop.

More work means more heat and more friction material worn away. That is why Nissan put disc brakes up front and the smaller, cooler-running drum brakes at the rear: the rear only needs to contribute a modest share of braking and hold the car with the parking brake. The practical result for an owner is simple:

• Front pads are the most frequent brake replacement on a Versa.
• Front rotors often get replaced with the second pad set, or sooner if they are warped, grooved or rusted.
• Rear shoes typically last much longer, but they are not lifetime parts, and the drums hide problems you cannot see from outside.

City driving, short trips, hills and a heavy right foot all shorten front pad life. Rear shoe life is affected more by things like a leaking wheel cylinder, a stuck self-adjuster, or driving with the parking brake partially applied.

Symptoms: Is It the Front or the Rear?

Because the two ends use different hardware, they tend to complain in different ways.

Front disc brake symptoms

• High-pitched scraping while driving, even with your foot off the pedal. Nissan's manual describes exactly this: the front pads have audible wear indicators that scrape when a pad needs replacing. Treat that sound as a deadline, not a suggestion.
• Grinding metal-on-metal: the pads are worn to the backing plate and the rotor is being damaged. Rotors must be replaced at this point.
• Steering wheel shake or pedal pulsation during braking at speed: usually uneven rotor thickness or pad deposits on the rotors.
• Pull to one side under braking: a sticking caliper slide pin, a seized caliper piston, or uneven pad wear side to side.

Rear drum brake symptoms

• Parking brake lever pulls up higher than it used to, or the car creeps on a hill with the lever set. The shoes are worn or out of adjustment.
• Low or long brake pedal that improves if you pump it: rear shoes too far from the drums because the self-adjuster is not working.
• Scraping or grinding from the rear with no front wear: shoe lining worn through, or a broken spring letting a shoe drag.
• Wet residue on the inside of a rear tire or backing plate: a leaking wheel cylinder, which also contaminates the shoes.
• Rear wheel hot after a drive: a shoe dragging from a stuck adjuster, seized cable or parking brake left partly on.

Occasional light squeaks during gentle stops are normal on these cars; Nissan's manual says so directly. A persistent scrape, grind or pull is not.

One more check that is not a wear issue: a 2014-2015 Versa Note that feels like the brake takes a moment to reach may be affected by NHTSA recall 15V-507, where the driver's shoe could catch the lower edge of the center console trim on the way from the gas pedal to the brake. The dealer remedy trims that panel at no charge. Owners of other Versa model years should also run the VIN on the NHTSA recall lookup before assuming the brakes themselves are at fault.

What to Replace on the Front

A proper front brake job on a Versa is more than slapping in pads.

• Pads: always replace both sides of the axle together. See our brake pads and ceramic brake pads for low-dust daily-driver options.
• Rotors: replace if they are below the minimum thickness stamped on the rotor, badly grooved, heat-spotted or causing pulsation. On a car this light, new brake rotors are usually the better choice than machining thin factory rotors.
• Pad hardware: the abutment clips and anti-rattle springs. Power Stop's technical guidance points out that worn hardware can cause binding, pulling, uneven wear and noise, and that old clips can let pads shift. We carry a Versa front brake hardware kit for 2012-2019 made for this job.
• Caliper slide pins: clean and lubricate with the correct high-temperature brake grease, and replace boots that are torn. If a caliper piston is sticking or leaking, replace the caliper; see brake calipers.

Torque the caliper bolts and lug nuts to the values in the factory service manual, and bed in the new pads with a series of moderate stops so they transfer an even layer of material to the rotors.

What to Replace on the Rear

Rear drum service is less frequent but a little more involved. When the drums come off, inspect everything, not just the lining thickness.

• Shoes: replace as an axle set when the lining is worn to the service limit or contaminated with fluid or grease. Contaminated shoes cannot be cleaned. Browse brake shoes.
• Drums: replace if scored, cracked, out of round, or worn beyond the maximum diameter cast into the drum.
• Springs and adjuster: return and hold-down springs lose tension with years of heat cycles, and a sticky self-adjuster is the most common cause of a low pedal on drum-brake cars. A drum brake hardware kit is inexpensive insurance.
• Wheel cylinders: peel back the dust boots. Any wetness means replace the cylinder, and replace the shoes it soaked.
• Parking brake cables: check that they move freely and fully release.

After a shoe or drum replacement, Nissan's owner's manual calls for a parking brake break-in procedure, described in the service manual, to restore full parking brake holding power. Because the rear shoes self-adjust through the parking brake on this car, set and release the parking brake several times after the job to bring the shoes into adjustment before road testing.

Brake Fluid, Difficulty and When to Do Both Ends

Every Versa in this range calls for DOT 3 brake fluid according to Nissan's owner's manuals. Brake fluid absorbs moisture over time, so follow the brake fluid interval in your Nissan maintenance schedule and flush it if it is dark or overdue, especially if you are replacing wheel cylinders or a caliper and will be bleeding the system anyway.

For a home mechanic with basic tools, front pads and rotors are an approachable job. The rear drums are harder: springs have to go back in exactly the right positions, and an incorrectly assembled adjuster will give you a low pedal. Take a photo of one side before disassembly and work one side at a time so the other side is always a reference.

You do not need to replace the fronts and rears at the same time; they wear at very different rates. A sensible pattern is to inspect the rear shoes, drums and wheel cylinders every time you do the front pads, and replace rear parts when inspection says so. If you want the fronts done in one order, a matched set from our brake parts catalog keeps pads, rotors and hardware compatible.

Frequently Asked Questions

Does the 2012-2019 Nissan Versa have rear disc brakes?

No. Nissan's owner's manuals for the Versa Sedan and Versa Note of this generation describe front disc-type brakes and rear drum-type brakes. The rear wear parts are shoes and drums, not pads and rotors.

How do I know my Versa front brake pads are worn out?

The front pads have audible wear indicators. When a pad needs replacing you will hear a high-pitched scraping or screeching sound while driving, whether or not you are pressing the brake. Have the brakes checked as soon as you hear it.

Do I need to replace the rear brake shoes when I replace the front pads?

Not automatically. The rear shoes do much less work and usually last much longer. Inspect them, the drums and the wheel cylinders at each front brake job and replace only when they are worn, contaminated or damaged.

Why does my Versa parking brake lever pull up so high?

On this car the rear drum brakes self-adjust when the parking brake is applied. A high lever usually means worn shoes, a sticking self-adjuster or a stretched cable. Setting and releasing the parking brake a few times can help; if it does not, the rear drums need service.

What brake fluid does a Nissan Versa use?

Nissan specifies Genuine NISSAN Super Heavy Duty Brake Fluid or an equivalent DOT 3 fluid for these model years. Check the cap on your reservoir and your owner's manual to confirm for your exact car.

Should I replace brake hardware with new pads on a Versa?

Yes. Clips and springs lose tension from heat cycling, and worn hardware can cause noise, pulling, binding and uneven pad wear. New hardware is inexpensive and helps new pads wear evenly.

Sources

1. Nissan 2015 Versa Sedan Owner's Manual - front disc and rear drum self-adjusting brakes, audible pad wear indicators, DOT 3 fluid, parking brake break-in, ABS self-test and brake assist
2. Nissan 2019 Versa Sedan Owner's Manual - same front disc / rear drum layout and DOT 3 fluid at the end of the generation
3. Nissan 2015 Versa Note Owner's Manual - Versa Note uses front disc and rear drum brakes with DOT 3 fluid
4. Summit Racing: What is brake bias? - weight transfer to the front under braking and front bias up to 80 percent on front-wheel-drive cars
5. Power Stop: Do you need new hardware with new brake pads? - worn hardware causes binding, pulling, uneven wear and noise
6. NHTSA Recall 15V-507 owner notice - center console trim panel could delay the move from accelerator to brake pedal; dealer trims the panel free
