2008-2011 Mazda Tribute Brake Job Guide: Symptoms, Costs and the Right Parts

By Core Brake Parts Tech Team — Circleville, OH warehouse

A full brake job on a 2008-2011 Mazda Tribute means new pads and usually new rotors on the front axle, and new shoes, hardware and often drums on the rear axle. Mazda built the gas Tribute with ventilated 11.9-inch front discs and 10-inch rear drums, so the front and rear jobs are two very different kinds of work. The fronts wear out first and are a straightforward pad-and-rotor swap; the rears last longer but take more care to reassemble and adjust.

How the Brakes Are Built on This Tribute

The second-generation Tribute shares its platform with the Escape of the same years, and Mazda's 2009 specification sheet lays out the hardware: power-assisted ventilated front disc brakes, rear drum brakes, and a four-wheel anti-lock system with Electronic Brakeforce Distribution (EBD) and Brake Assist. The parking brake is foot operated - you press a pedal to set it - and it works through the rear drums, not a separate caliper.

The Tribute Hybrid is the one to double-check. Mazda's 2009 sheet lists rear drums as "new for HEV" that year and adds regenerative braking, which means the electric motor does part of the slowing. That tends to make hybrid pads and shoes last longer than on a gas Tribute. Because the rear setup changed for the hybrid, a 2008 Tribute Hybrid may not have the same rear hardware as a 2009-2011 - look behind the rear wheel or confirm by VIN before you order.

Symptoms That a Brake Job Is Due

Mazda's own owner's manual says occasional brake noise is normal, but a metal-to-metal sound, continuous grinding or continuous squeal means the linings may be worn out. It also calls out continuous vibration or shudder in the steering wheel while braking as a reason for inspection. In practice, here is how those symptoms map to parts on a Tribute:

• High-pitched squeal that comes and goes with braking - usually the front pad wear indicators touching the rotor. The pads are near the end of their life.
• Grinding - pad backing plate or shoe rivets against metal. Stop driving on it; the rotor or drum is now being damaged.
• Steering wheel shake while braking - front rotor thickness variation or runout. Pads alone will not fix it.
• Low pedal, or a pedal that feels better after pumping - often rear shoes out of adjustment, a sticking self-adjuster, or air or moisture in the fluid.
• Weak parking brake - worn rear shoes, a seized adjuster, or a stretched parking brake cable.
• BRAKE light on with the parking brake released - the manual says this indicates low brake fluid or a brake system malfunction. Low fluid often just means the pads are very worn, but also look for leaks at the rear wheel cylinders and hoses.
• ABS light on - the manual notes normal braking still works but the anti-lock function may be disabled. On a vehicle this age that is often a wheel speed sensor or a dirty tone ring, which is worth checking while the wheels are off.

Front Brake Job: Pads and Rotors

The front brakes do most of the stopping, so they wear first. The job is a conventional sliding caliper on a vented rotor.

1. Loosen the lug nuts, raise and support the vehicle on stands, and remove the wheels.
2. Remove the caliper, hang it from the suspension with wire so the hose is not stretched, then remove the pads and the caliper bracket.
3. Pull the rotor. Rust around the hub face is common on a Tribute of this age; clean the hub face down to bare metal so the new rotor sits flat. Mazda's manual stresses clean metal-to-metal contact between the wheel, hub and rotor.
4. Clean the bracket, fit new pad clips, and clean and lubricate the caliper slide pins with a high-temperature brake grease. A stuck pin causes the uneven pad wear that shortens the life of a new set.
5. Install the rotor, bracket, pads and caliper, and torque the caliper hardware to the value in the factory service manual.
6. Reinstall the wheels and torque the lug nuts to 100 lb.ft in a star pattern. Mazda asks you to retighten them after 500 miles whenever a wheel has been removed.

Should you replace the rotors? On most Tributes at this mileage, yes. Rotors that are below the minimum thickness cast into them, that have a deep lip or heat spots, or that cause a pedal pulse should be replaced rather than reused. Fresh front brake rotors with new ceramic brake pads give a quiet, low-dust result that suits a daily-driven compact SUV.

Rear Brake Job: Shoes, Drums and Hardware

The rear drums do a smaller share of the braking and usually outlast one or two sets of front pads, but they need attention. Mazda's maintenance schedule lists separate inspection items for disc brakes and drum brakes, and the drum inspection comes up less often. When the rear shoes are worn, the job looks like this:

• Drum removal - if the drum will not slide off, the shoes have usually worn a lip into it. Back off the star-wheel adjuster through the backing plate rather than prying on the drum.
• Shoes - replace as a full axle set, both sides at once.
• Springs, hold-downs and adjuster - Wagner's technical library notes that a worn adjuster lever or star wheel stops adjusting, which gives a low pedal, and recommends replacing the adjusting screw, star wheel, lever and the springs and retainers during a shoe job. A brake hardware kit covers most of this.
• Wheel cylinders - peel back the dust boots. Any wet fluid behind them means the cylinder leaks and must be replaced, or the new shoes will be contaminated.
• Drums - replace if they are scored, out of round, or past the maximum diameter stamped on them.
• Adjustment - adjust the shoes so the drum just drags lightly before final assembly, then check the parking brake. Keep left and right adjuster parts on their own side; they are side specific.

Work one side at a time so the other side is always there as a reference for where each spring goes. New rear brake shoes and hardware turn the rear job into a one-afternoon task for a careful home mechanic.

What to Replace Together, and What Drives the Cost

A Tribute brake job can range from pads only to a full four-wheel refresh, and the scope is what moves the price. The main drivers are:

• Pads only vs pads and rotors - rotors add substantially to the parts in a front job, but reusing worn rotors often brings the noise or pulse right back.
• One axle vs both - fronts are due far more often. Doing the rears at the same time saves a second trip only when the shoes are actually worn.
• Extra parts found on inspection - a seized caliper, a leaking wheel cylinder, a cracked hose or a stretched parking brake cable add parts and labor.
• Labor - the front pad-and-rotor job is quick for a shop. Rear drums take longer because of the springs and adjustment.
• Brake fluid - the manual specifies DOT 3 fluid. Old, dark fluid holds moisture; a flush while the system is open is cheap insurance.

Always replace pads, shoes and rotors in axle pairs. Mixing a new part on one side with a worn one on the other makes the Tribute pull under braking. Browse the full range of brake parts to match both axles.

Recalls and Safety Notes Worth Knowing

NHTSA's recall records for the Tribute show no recall on the brake system itself for these years, but two related campaigns are worth knowing before you work on it:

• 15E045000 - certain aftermarket front wheel bearings sold for 2001-2011 Tributes had incorrect dimensions, which the recall says can affect braking and steering. If the front bearings on your Tribute were replaced around 2015, have them checked.
• 14V282000 - a steering torque sensor issue that can cause a loss of electric power steering assist on 2008-2011 models. It is not a brake problem, but it is worth confirming it was done while the vehicle is in for service.

Enter your VIN on nhtsa.gov to see any open recall for your specific vehicle.

Frequently Asked Questions

Does the 2008-2011 Mazda Tribute have rear disc or drum brakes?

Mazda's 2009 specification sheet lists 10-inch rear drums with 11.9-inch ventilated front discs. The rear hardware changed for the hybrid in 2009, so a 2008 Tribute Hybrid should be checked visually or by VIN before ordering rear parts.

What brake fluid does the Tribute use?

The 2010 Tribute owner's manual specifies High Performance DOT 3 Motor Vehicle Brake Fluid, filled between the MIN and MAX marks on the reservoir.

Do I need to replace the rotors with the pads?

Not every time, but usually on a Tribute of this age. Replace them if they are below minimum thickness, have a deep lip or heat spots, or cause a pulse in the pedal or steering wheel.

Why is my pedal low after a rear brake job?

Most often the rear shoes are not adjusted close enough to the drums, or the self-adjuster was reassembled on the wrong side or is worn. Adjust the shoes, check the adjuster, and bleed the brakes if air got in.

What is the lug nut torque for a Tribute?

The 2010 owner's manual lists 100 lb.ft (135 N-m) for the M12 x 1.5 lug nuts, with a retorque after 500 miles.

Do Tribute Hybrid brakes wear differently?

Yes. The hybrid uses regenerative braking, so the motor does part of the slowing and the friction brakes typically last longer. The parts still wear, and rear drums that see little use can rust or stick, so inspect them on schedule.

Sources

1. Mazda North American Operations - 2009 Tribute specifications - front disc and rear drum sizes, ABS with EBD and Brake Assist, foot-operated parking brake, hybrid rear drums and regenerative braking
2. Mazda USA - 2010 Tribute Owner's Manual - DOT 3 fluid, lug nut torque, brake noise and warning light guidance, disc and drum inspection schedule
3. NHTSA - Mazda Tribute recall records - campaigns 15E045000 and 14V282000
4. Know Your Parts (Wagner) - The Importance of Drum Brake Self Adjusters - adjuster wear, low pedal, which hardware to replace during a shoe job
