2008-2009 Ford Escape Brake Job Tools and Torque Specs

By Core Brake Parts Tech Team — Circleville, OH warehouse

A front brake job on a 2008-2009 Ford Escape is a basic hand-tool job: a jack and stands, a socket set, a caliper piston tool, brake cleaner, the right lubricants and a torque wrench. The one brake-related number Ford prints for owners is the wheel lug nut torque, 100 lb-ft (135 N-m) on M12 x 1.5 studs, rechecked after 500 miles. The caliper and bracket bolt values live in the factory service manual, and this guide explains how to treat them.

What brakes the 2008-2009 Escape uses

This generation of Escape uses front disc brakes and rear drum brakes, with four-wheel ABS described in Ford's owner guide. For the 2008 redesign Ford replaced the previous generation's rear disc brakes with rear drums. That split matters when you plan the job. The front pads and rotors do most of the stopping and wear first. The rear shoes wear much more slowly and are a separate job with different tools.

The parking brake is a foot pedal. Ford's owner guide says to press the pedal down until it stops, and notes that the parking brake applies only the rear brakes. On a rear-drum Escape that means the parking brake works through the rear shoes. If you ever have the rear drums apart, check parking brake operation before the wheels go back on.

Tools for a front pad and rotor job

• Floor jack and two jack stands. Never work under the vehicle on the jack alone. The owner guide shows the jacking locations, so use them.
• Breaker bar and a lug nut socket to break the wheel nuts loose before the wheel leaves the ground.
• Metric socket and wrench set for the caliper guide pin bolts and the caliper bracket bolts.
• Wire brush or a bracket cleaning tool for the rust on the caliper bracket abutments.
• Caliper piston compressor or a large C-clamp to push the piston back so the thicker new pads fit.
• Two lubricants. A silicone brake lube for the guide pins and boots, and a moly brake lube for the metal-to-metal points where the pad ears ride in the bracket.
• Brake parts cleaner and clean rags to clean the new rotor faces and the hub surface.
• Bungee cord or wire to hang the caliper so it never hangs on the brake hose.
• A click-type torque wrench that covers 100 lb-ft. An impact gun is fine for removal, but final tightening of lug nuts and caliper bolts should be done by hand to a value.
• Penetrating oil and a rubber or dead-blow mallet if the rotor is rusted to the hub.

Torque specs and how to use them

Wheel lug nuts: Ford's 2009 Escape owner guide lists 100 lb-ft (135 N-m) for M12 x 1.5 studs. The footnote says the value is for threads free of dirt and rust, and to use only Ford recommended replacement fasteners. Run the nuts down snug, lower the vehicle so the tire carries weight, then tighten in a star pattern to the full value. Ford also says to retighten to spec at 500 miles (800 km) after any wheel disturbance, including a tire rotation.

Caliper bracket bolts and guide pin bolts: Ford does not print these in the owner guide. Use the value in the factory service manual for your exact build. Do not borrow a number from another vehicle, because bracket bolt torque varies a lot. One trade publication puts the range across vehicles at 30 to 110 ft-lb and notes that some bracket bolts are torque-to-yield or need liquid thread locker. If the service manual calls a bolt one-time-use, replace it rather than reusing it.

Do not use an impact gun to install guide pin bolts. Spinning the pin in its bore can damage it. Snug by hand, then torque.

The job, step by step

1. Park on level ground, set the parking brake and chock the rear wheels. Crack the front lug nuts loose, raise the front and set it on stands.
2. Check the brake fluid reservoir. Ford notes that the level drops slowly as pads wear and rises when new parts go in, so if someone topped it to MAX on worn pads, pushing the pistons back can overfill it. Remove a little fluid first if needed.
3. Remove the guide pin bolts, lift the caliper off and hang it. Remove the pads, then the two bracket bolts and the bracket.
4. Pull the rotor. If it is rusted to the hub, use penetrating oil and the mallet on the hat, not the braking surface.
5. Clean the hub face with the wire brush so the new rotor sits flat. Rust on the hub face is a common cause of runout and pedal pulsation later.
6. Clean the bracket abutments down to bare metal. Wagner calls rust buildup and poor lubrication on caliper brackets a major cause of brake noise, premature wear and longer stopping distance. Install the new abutment clips.
7. Clean the guide pins in solvent and regrease them with silicone lube. Replace a torn boot. A neglected guide pin is the leading cause of uneven pad wear.
8. Clean the new rotor faces with brake cleaner, install the rotor, bolt the bracket on and torque it to the service manual value.
9. Compress the piston, install the pads in the correct orientation, refit the caliper and torque the guide pin bolts.
10. Pump the pedal until it is firm before you move the vehicle. The first pedal strokes only move the pistons back out to the pads.
11. Mount the wheels, lower the vehicle and torque the lug nuts to 100 lb-ft.

Which pads, and what to replace together

For the 2.3L four-cylinder Escape we carry two front pad options. EBC Greenstuff 6000 front brake pads (DP61709) for the 2008-2009 Escape 2.3L are a street pad suited to SUVs and daily driving. EBC Yellowstuff front brake pads (DP41709R) for the 2008-2009 Escape 2.3 are a higher-friction street and performance compound for owners who drive hard or carry loads. You can browse more fitments in our brake pads and brake rotors collections.

Replace pads in axle sets, both sides at once. Replace or resurface the rotors if they are below minimum thickness, scored, or show runout. If you reuse rotors, clean the old pad material off them: EBC's pad instructions call removing residue from the previous compound a vital step, or the bed-in period for the new material is extended considerably. If the bracket clips are worn or the guide pin boots are torn, a brake hardware kit is cheap insurance.

Because the rear brakes are drums, rear pads do not apply to this vehicle. If the rear shoes are worn, that is a separate job; see our brake shoes collection.

Brake fluid and bedding in

Ford's 2009 Escape Hybrid owner guide lists Motorcraft High Performance DOT 3 Motor Vehicle Brake Fluid, part PM-1-C, meeting WSS-M6C62-A or WSS-M6C65-A1. Confirm the grade on your own reservoir cap or owner guide before you add fluid, and never top up with silicone DOT 5 in a system built for DOT 3.

New pads and rotors need a bed-in to lay an even pad layer onto the rotor. EBC's instructions start by establishing full contact between new pads and rotors with a series of moderate stops before any hard use, and they note that pedal feel can be poor during bedding and improves as it goes. Follow the bedding instructions packed with your pads, avoid panic stops for the first stretch of driving, and do not sit with your foot hard on the brake after a hot stop.

Frequently Asked Questions

What is the lug nut torque on a 2008-2009 Ford Escape?

Ford's owner guide lists 100 lb-ft (135 N-m) for the M12 x 1.5 wheel studs on clean threads, and says to retighten to that value 500 miles after any wheel removal.

Does the 2008-2009 Escape have rear disc brakes?

No. For the 2008 redesign Ford switched the rear brakes from discs to drums. The rear uses brake shoes, and the foot-pedal parking brake works on the rear brakes only.

What are the caliper bracket bolt torque specs?

They are in the Ford factory service manual, not the owner guide. Bracket bolt values vary widely between vehicles, and some bolts are torque-to-yield or need thread locker, so use the manual value for your build rather than a number from another vehicle.

Do I need to bleed the brakes after replacing pads?

Not if you never opened the hydraulic system. Pushing the piston back does not let air in. If you replace a caliper or disconnect a hose, you must bleed that circuit.

Which brake fluid does the Escape use?

Ford's 2009 Escape owner documentation specifies a DOT 3 fluid (Motorcraft PM-1-C). Check your reservoir cap to confirm before adding fluid.

Why does my pedal go to the floor right after a pad change?

The pistons are still pushed back. Pump the pedal several times with the vehicle stopped until it is firm before you drive.

Sources

1. Ford 2009 Escape Hybrid Owner's Guide - lug nut torque 100 lb-ft / 135 N-m on M12 x 1.5, 500-mile recheck, pedal parking brake on rear brakes only, four-wheel ABS, fluid level behavior, Motorcraft DOT 3 PM-1-C
2. CarGurus 2008 Ford Escape review - 2008 redesign replaced rear discs with rear drums
3. Counterman, 4 Common Brake Job Mistakes - guide pin cleaning, bracket bolt torque range, torque-to-yield bolts
4. Wagner Tech Tip, Brake Caliper Cleaning and Lubrication - silicone vs moly lube, bracket rust effects
5. EBC Brakes pad bedding instructions - removing old pad residue, establishing full pad-to-rotor contact
