2006-2011 Honda Civic Parking Brake Problems and Adjustment

By Core Brake Parts Tech Team — Circleville, OH warehouse

On a 2006-2011 Honda Civic, a parking brake lever that pulls up too high, a car that rolls on a hill with the lever set, or a rear wheel that drags after release almost always comes back to three things: worn or out-of-adjustment rear brakes, a stretched or seized cable, or a parking brake that was never readjusted after a rear brake job. The fix is usually an adjustment at the nut under the center console, but only after the rear brakes themselves are healthy. Here is how the system works on this Civic, how to tell which problem you have, and how the adjustment is done.

How the Parking Brake Works on the 2006-2011 Civic

The eighth-generation Civic uses a hand lever between the front seats. The lever pulls a cable that splits to the two rear wheels, and the cable tension is set by an adjusting nut at the lever, reached by removing the rear trim of the center console. What that cable actually clamps at the wheel depends on which Civic you have, because Honda built this generation with two different rear brake designs.

Most sedans and coupes use rear drum brakes. In a drum, the parking brake cable hooks to a lever on the rear brake shoe and spreads the shoes against the drum. Higher trims and the performance and hybrid models use rear disc brakes, where the cable operates a lever on the rear caliper that mechanically pushes the caliper piston against the pads. Honda's 2009 specification sheets lay out which is which:

Equipment shifted slightly between model years, so do not guess from the trim badge alone. Look through the rear wheel spokes: if you see a rotor and a caliper, you have rear discs; if you see a closed metal drum, you have drums. The adjustment procedure and the parts you buy are different for each.

Common Parking Brake Problems and Their Symptoms

Lever travels too far before it holds

This is the most common complaint. Each click of the lever takes up cable slack, and Honda's service procedure specifies a set range of clicks for a properly adjusted brake. When the lever comes up well past that range, the slack is coming from somewhere: worn rear shoes or pads, drum self-adjusters that have stopped working, or a cable that has stretched. As Brake & Front End magazine notes, cables stretch over time and that slack shows up directly as extra lever travel.

Car rolls with the parking brake set

If the lever comes up to a normal height but the car still creeps on a slope, the force is not reaching the shoes or pads. Causes include a seized cable, a seized lever on the drum shoe or rear caliper, or friction material contaminated with oil or brake fluid. A leaking rear wheel cylinder on a drum Civic will soak the shoes and wipe out parking brake holding power along with rear braking.

Rear wheel drags or stays hot after release

A brake that will not fully release usually points to a cable that is corroded inside its housing, a parking brake lever on the caliper or shoe that is not returning, or an adjustment set too tight. Water getting past torn cable boots is a typical starting point for internal corrosion. Do not force a sticky lever; it may apply and then fail to release.

Brake warning light stays on

The brake light on the dash also reports the parking brake switch. If it stays lit with the lever fully down, check that the lever is truly at rest and the switch is making contact, then check the brake fluid level, since a low reservoir lights the same lamp.

Diagnose Before You Adjust

Adjusting the cable is the last step, not the first. Tightening the nut to cover up worn rear brakes just uses up the adjustment range and leaves you with a weak parking brake later. Work through it in this order:

1. Count the clicks. Pull the lever firmly and count. Compare to the range in the factory service manual for your exact model; disc and drum cars, and the Si, are not identical.
2. Inspect the rear brakes. On drum cars, pull a drum and check shoe lining, the wheel cylinder for leaks, the springs, and the self-adjuster. On disc cars, check pad thickness and whether the caliper lever moves freely and returns.
3. Inspect the cables. Look for torn boots, kinks, rust at the ends, and cable that does not slide back when the lever is released. Brake & Front End advises against spraying lubricants or solvents into a cable housing, since that can pull grime into the sheath and ruin it.
4. Then adjust. Once the friction parts and cables are good, set the tension at the lever.

How to Adjust the Parking Brake

The adjustment nut sits at the base of the lever under the rear section of the center console trim. The car has to be safely supported on stands or a lift with the rear wheels off the ground so you can spin them. Never work under a car held only by a jack.

Rear drum brake models

1. Remove the center console rear trim, release the lever fully, and loosen the adjusting nut.
2. Press the brake pedal several times. This lets the drum self-adjusters take up shoe clearance first, which the Honda procedure calls for before the cable is set.
3. Pull the lever up one click.
4. Tighten the adjusting nut until the rear brakes drag slightly when you turn the rear wheels by hand.
5. Release the lever fully and confirm the rear wheels turn without dragging. Readjust if needed.
6. Pull the lever and confirm it holds within the click range in the service manual, then reinstall the trim.

Rear disc brake models

1. Remove the console rear trim, release the lever fully, and loosen the adjusting nut.
2. Remove the rear wheels and confirm the parking brake lever on each rear caliper is resting against its stop pin. If it is not, the cable or caliper lever is binding and needs attention before any adjustment.
3. Clean the mating surfaces between the rotor and wheel, then reinstall the wheels.
4. Pull the lever one click and tighten the nut until the rear brakes drag slightly.
5. Release fully, confirm no drag, and check the lever click count against the specification. The service manual lists a different click range for the Si than for other disc models.

Tighten the wheel lug nuts to the value in the factory service manual. Brake & Front End's advice applies here: never set a parking brake by feel when the manual gives a procedure. Follow it exactly.

What to Replace and When

If inspection turns up worn parts, replace them before adjusting:

• Drum Civics: worn or contaminated shoes call for new rear brake shoes, and the springs and self-adjuster parts in a drum brake hardware kit are cheap insurance since weak springs and a sticky adjuster are what let the lever travel creep up. Replace shoes in axle sets. A leaking wheel cylinder must be replaced, and contaminated shoes cannot be cleaned and reused.
• Disc Civics (Si, Hybrid, EX coupe and others with rear discs): replace rear brake pads as an axle set, and inspect the rotors; our brake rotors collection covers replacements. If a caliper parking lever is seized or will not return to its stop, the fix is a rear brake caliper, since the parking mechanism is built into it.
• Cables: a cable that is stretched past the adjustment range, frayed, or seized in its housing gets replaced, not lubricated.

After any rear shoe, pad, caliper or cable work, the parking brake must be readjusted. On drum cars, Honda's shoe replacement procedure has you loosen the adjusting nut before the drum comes off, which means the cable is slack until you set it again.

How Hard Is This Job?

A straight cable adjustment is an easy job for a home mechanic with jack stands and basic hand tools: the console trim comes off, the nut is right there, and the check is done by spinning the wheels. Rear drum shoe replacement is moderate. The springs take patience, the parking brake cable has to be unhooked from the shoe lever, and a rusted drum can stick to the hub. The Honda procedure frees a stuck drum by threading bolts into the drum's service holes to push it off evenly. Rear disc pad work is also moderate, mainly because the caliper piston on a parking-brake caliper typically has to be rotated back rather than pushed. Cable replacement is the most involved, since the cables route under the car and up to the lever.

Not sure which parts fit your car? Start at our brake parts catalog and check fitment for your Civic's exact year and trim.

Frequently Asked Questions

Why does my Civic's parking brake lever come up so high?

Excess lever travel means slack in the system: worn rear shoes or pads, drum self-adjusters that are not working, or a stretched cable. Inspect the rear brakes first, then adjust the cable at the nut under the center console.

Does my 2006-2011 Civic have rear drums or rear discs?

Most DX and LX models, and the EX sedan, use rear drums. The Si, Hybrid and EX coupe use rear discs. Equipment varied by year, so look through the rear wheel to confirm before buying parts.

Where is the parking brake adjuster on a Civic?

It is the adjusting nut at the base of the hand lever, under the rear trim of the center console. There is no adjuster you need to reach under the car for a normal adjustment.

Do I need to adjust the parking brake after a rear brake job?

Yes. The adjusting nut is loosened during rear shoe service, and new shoes or pads change the clearance. Set the parking brake per the service manual after any rear brake, caliper or cable work.

Should I spray lubricant into a sticky parking brake cable?

No. Lubricants and solvents tend to wash grime deeper into the housing and shorten cable life. A cable that binds or will not return should be replaced.

Can a bad parking brake cause rear brake wear?

Yes. A cable or caliper lever that does not fully release keeps the rear shoes or pads in light contact, which causes heat, drag and fast wear on that wheel.

Sources

1. Honda News: 2009 Civic Sedan Specifications - rear drum vs rear disc by sedan trim and brake sizes
2. Honda News: 2009 Civic Coupe Specifications - rear drum vs rear disc by coupe trim and brake sizes
3. Honda Civic Service Manual: Parking Brake Adjustment (Drum Brake) - drum adjustment steps, pressing the pedal to set self-adjusters, specified click range
4. Honda Civic Service Manual: Parking Brake Adjustment (Disc Brake) - disc adjustment steps, caliper lever stop pin check, separate Si click range
5. Honda Civic Service Manual: Rear Brake Shoe Removal and Installation - loosening the adjusting nut before drum removal, freeing a stuck drum, shoe parking lever
6. Brake & Front End: Parking Brake Diagnostics, Repair and Maintenance - cable stretch and lever travel, not adjusting by feel, cable lubrication cautions
7. Brake & Front End: Parking Brake Cable Integrity - cable construction, boots and grommets, equalizer and holding failures
