2003-2009 Toyota 4Runner Brake Guide

By Core Brake Parts Tech Team — Circleville, OH warehouse

Short answer: The 2003-2009 4Runner (N210) uses vented disc brakes at all four wheels, 6-lug 6x139.7 hubs, and a drum-in-hat parking brake. Front rotors run about 319mm on V6 trims and 338mm on V8/Sport; rears measure near 312mm. This guide walks through the exact diagnostic steps, replacement thresholds, product comparisons, and cost breakdown so you can decide with confidence whether to DIY or take it to a shop.

Direct experience note: we ship these parts daily from our Circleville, OH warehouse to customers across the country. The picks in this guide reflect what fits, what lasts, and what our repeat-buyer mechanics come back for.

What to Know About 2003-2009 Toyota 4Runner Brakes

Understanding 2003-2009 Toyota 4Runner brakes matters because it directly affects stopping distance, brake pedal feel, and how often you replace consumables. Getting it right the first time saves both money and follow-up shop visits.

• The N210 fourth-gen 4Runner shares its platform with the Lexus GX470 and Land Cruiser Prado 120.
• All four corners use vented disc brakes; this generation has no rear drum service brakes.
• Wheels are 6-lug on a 6x139.7mm (6x5.5-inch) bolt pattern across every trim.
• Front rotor diameter varies by trim: roughly 319mm on V6 models and 338mm on V8 or Sport Edition.
• The parking brake is a drum-in-hat design with separate shoes inside the rear rotor center.
• Lug nut torque is 83 lb-ft (112 Nm); rear rotors measure approximately 312mm.

Spec Chart by Vehicle Class

How to Diagnose or Replace

1. Loosen the six lug nuts, lift the corner, and secure the 4Runner on a jack stand.
2. Remove the wheel, then unbolt the caliper slider bolts and hang the caliper aside.
3. Slide out the old pads and inspect the vented rotor for scoring or heat cracks.
4. Remove the two caliper-bracket bolts, then pull the rotor off the hub studs.
5. For rear rotors, back off the parking-brake shoe adjuster so the drum-in-hat rotor releases.
6. Mount the new rotor, torque the bracket bolts, fit the pads, and reseat the caliper.
7. Torque lug nuts to 83 lb-ft in a star pattern, then bed the brakes gently.

Once diagnosis is complete, order the exact replacement parts for your vehicle - fitment matters. Related 2003-2009 Toyota 4Runner brakes products are listed in the next section.

Recommended Parts and Where to Buy

Every product below is in stock at our Circleville, OH warehouse and ships same-day when ordered before 2 PM Eastern. Free shipping on orders over $75.

• Brake Pads
• Brake Rotors
• Bosch
• Brake Parts

If your exact vehicle is not listed, use the site search or filter the full brake parts collection by year and make.

Cost Breakdown - DIY vs Shop

DIY savings scale with vehicle size and job complexity. A full-size truck brake job saves $450-700 in labor. For most passenger cars, plan on 90-120 minutes per axle for pads only, 2-3 hours for pads plus rotors.

Install Tips - Where Most DIYers Go Wrong

• Torque lug nuts to 83 lb-ft (112 Nm) in a star pattern to prevent rotor runout and warping.
• V8 and Sport Edition trims use the larger 338mm front rotor; verify diameter before ordering.
• Rear parking-brake shoes live inside the rotor hat; inspect and adjust them during any rear rotor job.

Frequently Asked Questions

What's the short answer on 2003-2009 Toyota 4Runner brakes?

The 2003-2009 4Runner (N210) uses vented disc brakes at all four wheels, 6-lug 6x139.7 hubs, and a drum-in-hat parking brake. Front rotors run about 319mm on V6 trims and 338mm on V8/Sport; rears measure near 312mm.

How much does 2003-2009 Toyota 4Runner brakes cost?

It depends on your vehicle and how much you replace. For example, front pads runs about $30-$80 in parts for a DIY job, or $150-$300 installed at a shop with labor included. The full cost breakdown is in the table above.

What should I check first?

Key things to check: The N210 fourth-gen 4Runner shares its platform with the Lexus GX470 and Land Cruiser Prado 120; All four corners use vented disc brakes; this generation has no rear drum service brakes.

Can I do this job myself?

Many DIYers can with basic tools. The first steps are: Loosen the six lug nuts, lift the corner, and secure the 4Runner on a jack stand; Remove the wheel, then unbolt the caliper slider bolts and hang the caliper aside; Slide out the old pads and inspect the vented rotor for scoring or heat cracks. The complete step-by-step is above.

Key Takeaways

• The 2003-2009 4Runner (N210) uses vented disc brakes at all four wheels, 6-lug 6x139.7 hubs, and a drum-in-hat parking brake. Front rotors run about 319mm on V6 trims and 338mm on V8/Sport; rears measure near 312mm.
• Measure friction material and rotor thickness at every tire rotation - catches wear before it becomes damage.
• Replace pads at 3 mm; below 2 mm is unsafe.
• Loaded calipers (with brackets, pads, and hoses) save 1-1.5 hours of labor per side over bare calipers.
• Bed new pads properly with 8-10 medium stops from 40 to 10 mph.
• Free shipping on orders over $75; same-day shipping on in-stock orders before 2 PM Eastern.
