Most brake noise on a 1999-2000 Lexus RX300 comes from four places: pad wear indicators squealing when the pads are thin, grinding from pads worn to the backing plate, a pulsing pedal from uneven rotor thickness, and rattles or squeaks from dry or worn caliper hardware. The RX300 has disc brakes at all four corners plus a small drum-style parking brake inside the rear rotor hat, so a noise can come from the pads, the rotors or the parking brake shoes. Match the sound to the cause below before you buy parts.
How the RX300 Brake System Is Laid Out
The first-generation RX300 uses disc rotors front and rear; complete front-and-rear rotor kits are sold for the 2000 model, which confirms four-wheel discs. Each front corner has a caliper clamping two pads against the rotor, and each rear corner has its own caliper and rotor. The parking brake does not use the rear calipers. Instead, a pair of parking brake shoes sits inside the hat (center section) of each rear rotor and presses outward against a small drum surface when you set the brake. Lexus lists these parking brake shoes for every RX300 from 1999 through 2003, with a different part for 1999-2001 than for 2002-2003.
That layout matters for diagnosis. A scrape that only happens with the parking brake partly engaged, or a rear noise that remains after new pads, often points to the shoes inside the rotor hat rather than to the pads.
Match the Noise to the Cause
| What you hear or feel | Most likely cause | What to check |
|---|---|---|
| High-pitched squeal while driving that stops when you brake | Pad wear indicator touching the rotor | Pad thickness at all four corners |
| Squeal only when braking, pads still thick | Vibration between pad, shim and caliper | Shims, anti-rattle clips, slide pin lubrication |
| Metal-on-metal grinding | Pad friction gone, backing plate on rotor | Rotor surface for deep scoring |
| Pulsing pedal or steering wheel shake when stopping | Disc thickness variation from rotor runout | Rotor runout and thickness variation |
| Rear scraping, worse with parking brake use | Parking brake shoes dragging in the rotor hat | Parking brake adjustment and shoe lining |
| Clunk or rattle over bumps | Missing or worn anti-rattle clips, loose caliper | Hardware and caliper mounting bolts |
Squeal
Wagner's brake noise guidance puts it plainly: vibration is the main source of noise in a brake system. On a vehicle this age that vibration usually comes from rust on the hub face, anti-rattle clips that have lost their tension from years of heat, guide pins that bind or are corroded, and missing or dry shims. If the squeal happens while you are driving and goes quiet when you press the pedal, it is more often the wear indicator tab riding on the rotor, which is a warning that the pads are nearly done.
Grinding
Grinding means steel is touching the rotor. That can be a pad worn through to its backing plate, a rock or rust flake trapped between the pad and rotor, or a rusted rotor edge after the vehicle sat. If the pads are gone, the rotor face is almost always scored too deep to reuse, and continued driving can damage the caliper piston. Replace the pads and rotors together on that axle.
Pulsation
A pedal that pulses under braking is usually blamed on "warped rotors," but brake makers describe the real cause as disc thickness variation (DTV). Wagner explains that when a rotor has excessive lateral runout it wobbles side to side, the pads touch one spot more than another on each revolution, and over time part of the rotor becomes thinner or builds up pad material. As those thick and thin sections pass through the caliper, brake fluid is pushed back and forth, and you feel it as a pulse in the pedal. Wagner notes that most vehicles have lateral runout specifications of two thousandths of an inch or less, and Power Stop states that a thickness variation larger than 0.006 inch (0.15 mm) indicates DTV and may call for replacement.
Common Causes on a High-Mileage RX300
- Rust on the hub mounting face. Wagner identifies rust buildup between the hub and rotor as a leading cause of runout. Even a thin layer tilts the rotor slightly, which starts the DTV cycle again on brand-new rotors.
- Uneven lug nut torque. Power Stop lists uneven clamping force among the causes of DTV. An impact gun used without a torque wrench is a common culprit after tire service.
- Tired caliper hardware. Clips, springs and slide pins on a vehicle more than twenty years old have seen many heat cycles. Weak clips let pads move and chatter.
- Sticking calipers. A seized slide pin or piston keeps one pad dragging, which overheats that rotor and wears the pads unevenly. Look for one wheel hotter than the others after a drive, or a pull to one side.
- Parking brake shoes. If the shoes are out of adjustment or the lining has come loose, they can drag against the drum surface inside the rear rotor hat.
The Fix and Which Parts to Use
Start with an inspection: pull the wheels, measure pad thickness, look at both faces of each rotor, and check that each caliper slides freely. Then fix it at the source.
- Thin pads, rotors in good shape: replace pads with new hardware and lubricate slide pins and contact points. Quality ceramic brake pads suit a daily-driven luxury SUV because they run quiet and low-dust.
- Grinding or scored rotors: replace pads and brake rotors as a pair on the axle. Power Stop notes that replacement is often more cost-effective than resurfacing.
- Pulsation: replace the rotors, then clean the hub face down to bare metal before installing the new ones, as Wagner recommends. Measure lateral runout after installation and torque the lug nuts evenly in a star pattern to the value in the factory service manual.
- Sticking or leaking caliper: replace the calipers in pairs. We carry a front brake caliper pair with brackets for the 1999-2001 Lexus RX300, which also gives you fresh bracket surfaces.
- Rear scraping from the parking brake: inspect and replace the parking brake shoes and adjust them. The small drum surface in the rotor hat is not a practical machining surface, so replace the rear rotor if that surface is worn.
What to Replace at the Same Time
- Hardware kit. New abutment clips and springs are cheap insurance against squeal. See our brake hardware kits.
- Brake fluid. Flush if the fluid is dark or its service history is unknown, using the fluid type printed on the master cylinder cap.
- Brake hoses. Rubber hoses on a 25-year-old vehicle can crack or swell internally and hold pressure on a caliper. Replace any that are cracked or soft with new brake hoses.
Also check the recall history. NHTSA campaign 99V012000 covered 6,503 1999 RX300s equipped with the optional traction control system: the rear brake tube distribution was improperly designed, so if one of the dual brake lines failed, the vehicle could feel unstable under braking. The remedy was for dealers to install modified brake tubes. It is not a noise issue, but if you own a 1999 with traction control, confirm the work was done.
How Hard Is the Job?
Front pads and rotors on the RX300 are a moderate home job with basic hand tools, a torque wrench and a way to push the caliper piston back. The rear takes longer because the rotor has to come off over the parking brake shoes; if the rotor is stuck, backing off the parking brake adjuster helps. After any pad or rotor change, bed the brakes. Wagner's burnishing procedure is 20 slow-downs from 50 mph to 20 mph with light pedal pressure and 30 seconds between each, which mates the pad to the rotor and helps prevent both noise and vibration. For everything else this vehicle needs, start at our brake parts collection.
Need the part? Shop Brake Pads & Kits at Core Brake Parts
Filter by your exact year, make, and model — every part ships from our Circleville, OH warehouse, free over $75.
Shop Brake Pads & Kits →Frequently Asked Questions
Why do my new RX300 brakes squeal?
New pads squeal when the shims were left off or not lubricated as the pad maker specifies, when old clips were reused, or when the pads were never bedded. Check that the caliper slide pins move freely and follow a proper break-in procedure.
Are my RX300 rotors warped if the pedal pulses?
Usually not in the literal sense. Brake manufacturers describe the cause as disc thickness variation, often started by rust on the hub face or lateral runout. Replacing the rotors without cleaning the hub can bring the pulsation right back.
Does the 1999-2000 RX300 have rear drum brakes?
No. It has rear disc brakes. The only drum-style part at the rear is the parking brake, which uses shoes inside the hat of each rear rotor.
Can I replace only the front pads if the rear is quiet?
Yes. Pads are replaced by axle, not all four corners at once. Measure the rear pads and check the parking brake shoes while the wheels are off so you know how much life is left.
Is the 1999 RX300 brake line recall related to noise?
No. Campaign 99V012000 addressed rear brake tube distribution on 1999 models with traction control and affects stability if a brake line fails. It will not cause squeal or grinding, but it is worth confirming it was completed.
Sources
- NHTSA recall 99V012000 record (Justia) - 1999 RX300 with traction control, 6,503 units, rear brake tube recall and remedy
- Wagner Brake - Brake Pedal Pulsation and Disc Thickness Variation - runout causes DTV, two-thousandths runout spec, hub rust cleaning
- Wagner Brake - Brake System Noise - vibration as noise source, hardware and shim guidance, burnishing procedure
- Power Stop - Pulsing Brake Pedal and DTV - DTV causes, 0.006 inch threshold, replace vs resurface
- Detroit Axle - 2000 Lexus RX300 front and rear rotor kit - confirms front and rear disc rotors
- Genuine Lexus RX300 Parking Brake Shoe - drum-style parking brake shoes, 1999-2003 fitment
