1994 Pontiac Grand AM Front vs Rear Brakes: What Wears First and What to Replace

By Core Brake Parts Tech Team — Circleville, OH warehouse

On a 1994 Pontiac Grand Am, the front brakes wear first, and it is not close. The car uses front disc brakes with pads and rear drum brakes with shoes, and because the front of the car carries more of the load during a stop, the front pads and rotors usually need attention well before the rear shoes do. The rear drums still need regular inspection, because they have no audible wear warning and they rely on a self-adjuster that can quietly stop working.

How the 1994 Grand Am brake system is laid out

GM's owner's manual for the 1994 Grand Am states it plainly: the car has front disc brakes and rear drum brakes. Up front, a caliper squeezes two pads against a rotor. At the rear, a wheel cylinder pushes two curved shoes outward against the inside of a drum. The owner's manual also covers the anti-lock system, which GM describes as working the brakes separately at each front wheel and at the rear wheels when a wheel is about to lock.

The hydraulic system is split into two parts, so if one half develops a leak the other half can still stop the car. That is a safety backup, not a reason to keep driving: GM says that if the red brake warning light comes on while driving, you should pull off and stop carefully, and have the car towed if the light stays on.

Why the front brakes wear out first

When you brake, the car's weight shifts toward the nose. The front tires press harder into the road and can put more stopping force down, so the system is designed to send more of the braking work to the front. The front disc brakes turn more of the car's motion into heat, and friction material that does more work wears faster. The rear drums do a smaller share of the stopping, partly so the rear wheels do not lock before the fronts and push the car into a spin.

That balance between front and rear is set by the factory parts. GM warns in the owner's manual that if someone installs brake linings that are wrong for the car, the balance between the front and rear brakes can change for the worse. That is a good reason to buy pads and shoes listed for your exact car instead of a close match.

Symptoms: front brakes versus rear brakes

Front disc brake symptoms

• High-pitched squeal while driving. The front pads have built-in wear indicators that make a warning sound when the pads are worn. GM notes the sound can come and go or be heard all the time while the car is moving, but it may stop while you press the pedal firmly.
• Grinding. If the squeal is ignored long enough, the pad backing plate can reach the rotor. GM warns that driving on worn-out pads can lead to costly brake repair, and that usually means rotors as well as pads.
• Pulsing pedal or steering shake when stopping. This points to rotor thickness variation, which calls for new brake rotors or resurfacing if the rotors are still within spec.
• Pulling to one side. A sticking caliper or contaminated pad on one side can cause this.

A light squeal when the brakes are first or gently applied is not always a problem. GM says some driving conditions and climates cause it without anything being wrong.

Rear drum brake symptoms

• A rubbing or scraping noise from the rear. The rear drums have no wear indicator. GM's advice is that if you hear a rear brake rubbing noise, have the rear linings inspected.
• A pedal that goes down farther than normal. GM says this can mean the rear drum brakes need adjustment, and the fix it gives is backing up and firmly applying the brakes a few times.
• Weak parking brake. The parking brake works through the rear shoes, so worn shoes or a stuck adjuster show up here.
• Wet residue inside the wheel or on the tire sidewall. That points to a leaking wheel cylinder, which also contaminates the shoes.

The rear self-adjuster: the part people forget

Drum brakes have a self-adjuster, usually a threaded screw with a notched star wheel and a lever that turns it. As the shoes wear, the adjuster moves them outward so the pedal stays high. Brake parts technical guidance explains that the adjuster cannot turn while brake pressure is applying the shoes, and that adjustment mostly happens when the brakes are applied in reverse or when the parking brake is set.

That is why a car driven mostly forward with gentle braking can end up with rear shoes that sit too far from the drum. The front brakes then do even more of the work, and the pedal gets lower. Over time, the lever and star wheel wear against each other, and a groove worn into the lever can stop the adjuster from working. The same guidance recommends replacing the adjusters instead of trying to repair them, and notes that the adjuster is most active during the first 100 or more miles after new shoes go in.

GM also covers the front brakes: the disc brakes adjust for wear every time you make a moderate stop. If you almost never brake more than lightly, the manual suggests carefully making a few moderate stops about every 1,000 miles so the brakes adjust properly.

What to replace, and what to replace with it

Front brake job

For a front job on the Grand Am, plan on new brake pads as a full axle set. GM says brake linings should always be replaced as complete axle sets, never one side at a time. Measure the rotors against the minimum thickness cast or stamped on them. If they are worn below it, scored or causing a pulsation, replace them as a pair. Ceramic brake pads are a common choice for a daily driver because they tend to run quieter with less dust. Fresh clips and slide hardware from the brake hardware kits collection help the new pads move freely.

Rear brake job

If the rear shoes are worn, replace them as an axle set along with the springs and self-adjusters. Old springs lose tension and old adjusters wear, and reusing them is a common reason a new rear brake job leaves a low pedal. Inspect the drums for scoring and check them against the maximum diameter marked on the drum. Pull back the wheel cylinder boots; any fluid behind them means the cylinder should be replaced. Shop brake shoes for your car here.

Do the rears when you do the fronts?

Not necessarily replace, but always inspect. GM says that when the front brakes are replaced, the rear brakes should be inspected too, and that the rear drums should be removed and inspected each time the tires are removed for rotation or changing. With the drum off, you can see shoe thickness, leaks and whether the adjuster turns freely.

Fluid, pedal feel and the booster

The 1994 Grand Am uses DOT-3 brake fluid. GM calls for Delco Supreme 11 or an equivalent DOT-3 fluid from a sealed container, and warns that even a few drops of mineral oil such as engine oil in the brake system can damage parts badly enough that they must be replaced.

The fluid level drops slowly as the front pads wear, then comes back up when new pads push the caliper pistons back. For that reason GM advises against topping off the reservoir as pads wear. A falling level that is not explained by pad wear means a leak that needs fixing.

If the pedal is hard to push while the engine is running, the problem is usually not pads or shoes. A hard pedal points to the vacuum brake booster or its vacuum supply. We carry a vacuum power brake booster for the 1994 to 1998 Pontiac Grand Am, and our brake boosters collection has other options.

How hard is the job?

The front pad and rotor job is one of the more approachable brake jobs for a home mechanic with basic hand tools, jack stands and a torque wrench. Tighten caliper bolts and lug nuts to the values in the factory service manual. The rear drum job takes more patience: the springs are strong, the parts have to go back in the right order, and the adjuster must be set so the drum just slides on with light drag. Take a photo of one side before you take it apart and work on one side at a time so the other side is a reference.

After any brake job, break in the new linings gently. GM's manual advises avoiding hard stops for about the first 200 miles, because hard stops on new linings can cause early wear. Then make a few firm stops in reverse to set the rear adjusters.

Frequently Asked Questions

Does a 1994 Pontiac Grand Am have rear disc or drum brakes?

Drum brakes. GM's owner's manual for the 1994 Grand Am says the car has front disc brakes and rear drum brakes.

How often do the rear brakes need replacing compared to the fronts?

Less often, because the front brakes do most of the stopping. There is no fixed ratio, so inspect the rear shoes whenever the tires come off for rotation, as GM recommends, and replace them when they are worn.

Why is my Grand Am brake pedal lower than it used to be?

A common cause is rear drum brakes that are out of adjustment. GM suggests backing up and firmly applying the brakes a few times. If the pedal stays low or keeps dropping, have the system checked for worn shoes, a seized adjuster or a fluid leak.

Can I replace brake pads on just one front wheel?

No. GM says brake linings should always be replaced as complete axle sets, meaning both front wheels together or both rear wheels together.

What brake fluid does a 1994 Grand Am take?

DOT-3. The owner's manual calls for Delco Supreme 11 or an equivalent DOT-3 brake fluid from a sealed container.

My ABS light is on. Do I still have brakes?

According to GM, if the ABS light is on but not flashing and the red brake warning light is off, you still have regular brakes but no anti-lock. If the ABS light is flashing, GM says to pull off, stop carefully and have the car towed for service.

Sources

1. GM, 1994 Pontiac Grand Am Owner's Manual - front disc and rear drum layout, pad wear indicators, rear drum inspection, axle-set replacement, adjustment, DOT-3 fluid, ABS and warning-light behavior, lining break-in
2. Know Your Parts, The Importance of Drum Brake Self Adjusters - how the self-adjuster works, lever wear, replace rather than repair, adjuster most active after new shoes
3. CarsDirect, 1994 Pontiac Grand Am Trim Comparison - front disc and rear drum brakes across 1994 trims
