1991-1996 Dodge Stealth Brake Upgrade Options

By Core Brake Parts Tech Team — Circleville, OH warehouse

The best brake upgrade for a 1991-1996 Dodge Stealth is almost never a big brake kit. On a car this old the real gains come from a fresh set of correctly matched pads, rotors that are still above minimum thickness, new front rubber hoses, and clean fluid. Do those four things first and the car stops the way the factory intended, with far better pedal feel than most Stealths still on the road today.

This guide covers what the car actually came with, what changed for 1994, and how to choose between pad compounds without guessing.

What your Stealth came with from the factory

Every Dodge Stealth uses four-wheel disc brakes. There is no rear drum brake on this car in the conventional sense. The parking brake is a small drum built into the hat of the rear rotor, which is why a rear rotor for a Stealth looks like it has a shallow drum cast into the center. That matters when you buy rear rotors: the parking brake shoes ride inside that hat, and a rotor with a scored or out-of-round hat will give you a parking brake that will not hold on a hill even with new shoes.

On the all-wheel-drive R/T Twin Turbo, the front brakes are ventilated iron rotors clamped by four-piston rigid iron calipers. The rear brakes on 1991-1993 cars use ventilated rotors with single-piston floating calipers. That four-piston front caliper was genuinely serious hardware for the early 1990s and it is still capable today, provided the pistons are not seized and the slide hardware is free.

The front-wheel-drive, normally aspirated Stealth is a different car underneath. The Stealth 316 technical reference notes that the normally aspirated FWD cars use the same front brake setup as the 1993-1999 DSM turbo cars, so FWD parts are not interchangeable with R/T Twin Turbo parts and the rotor dimensions are different. Always order by drivetrain, not just by year.

1991-1993 versus 1994-1996: the brake sizes changed

Mitsubishi enlarged the brakes on the AWD cars for the 1994 model year. This is the single most common ordering mistake on this platform, because "1991-1996 Dodge Stealth" looks like one part number range and it is not.

The 1994-and-later setup is a meaningful step up: roughly 19 mm more front rotor diameter, 11 mm more rear rotor, and a rear caliper with two pistons instead of one. If you own a 1991-1993 AWD car, swapping to the later brakes is the classic Stealth brake upgrade, and it is a swap of factory parts rather than a fabrication project. Measure your existing rotors before you order anything, because a previous owner may already have done it.

One note on rotor thickness: 30 mm front and 20 mm rear are the new dimensions, not the wear limit. The discard thickness is stamped on the rotor hat or listed in the factory service manual, and a rotor below it must be replaced rather than machined. On a car of this age, most used rotors are already too thin to resurface, which is why new brake rotors are usually the cheaper answer than a machine shop visit.

Pad compound: the upgrade that changes the most

Pads change how the car feels more than any other single brake part, and they cost the least. EBC publishes clear positioning for its three street compounds, and the Stealth is a car where the differences actually matter because it is heavy for its size and makes real power in turbo form.

Greenstuff 2000

EBC describes Greenstuff 2000 as a medium to low dust material offering a nominal 10-15 percent brake improvement, with a nominal friction coefficient of 0.55. EBC positions it for spirited street use on lighter sports sedans and hot hatches and states it is not ideal for track use, recommending Redstuff for heavier, faster cars. On a Stealth, that makes Greenstuff a sensible rear-axle choice, where loads are lower, paired with something stronger up front. Our Greenstuff 2000 rear pad set DP21098 for the 1994-1996 Stealth 3.0L 4WD is the direct fit for late AWD cars.

Redstuff ceramic

Redstuff is EBC's copper-free, ceramic-granule-enhanced organic street pad. EBC claims very minimal rotor damage characteristics and a large dust reduction over conventional materials, with a nominal friction coefficient of 0.5, and explicitly rates it at zero percent for track and race use. This is the pad for the owner who wants a clean wheel and a quiet car and does not do track days. We list Redstuff front pads for both drivetrains: DP3954C for the 1991-1996 Stealth 3.0 2WD and a Redstuff front set for the 1991-1993 Stealth 3.0 4WD.

Yellowstuff

Yellowstuff is EBC's aramid-fibre street and light-track compound. EBC states it has excellent cold bite with high-temperature fade resistance and is ECE brake safety tested, meaning it must work from cold. EBC gives Yellowstuff a green fade threshold of 400 degrees C (750 degrees F), which it calls the maximum expected temperature in fast street driving, and notes that track conditions can push brake temperatures above 500-600 degrees C. EBC is also direct about the trade-off: these are not low dust pads. If you drive your Stealth hard on back roads or do an occasional track day, the Yellowstuff front set DP41097R for the 1991-1993 Stealth 3.0 4WD is the honest choice. Browse the full range in brake pads.

Hoses and fluid before you spend on a big brake kit

There is a specific, documented reason to look hard at the front brake hoses on this car. NHTSA recall campaign 96V143003 covers the Stealth for a condition in which, under full lock steering and full suspension travel, the left or right front wheel-side brake hose can crack, resulting in brake fluid leakage. NHTSA states the consequence is illumination of the brake warning lamp and a reduction in braking effectiveness. The remedy was replacement of the left and right front wheel-side hoses with revised hose assemblies.

That recall was issued in 1996. Any hose on the car today is decades old regardless of whether the recall was performed, and old rubber hose swells under pressure, which is felt as a soft, long pedal that no amount of bleeding fixes. Replacing the front brake hoses is the cheapest firm-pedal upgrade available on a Stealth, and it should be done before anyone spends money on larger calipers.

Fluid is the other item. Brake fluid is hygroscopic, and water lowers the boiling point, which is exactly what produces a pedal that goes long after three hard stops down a hill. Flush with the DOT specification printed on your master cylinder reservoir cap and in the factory service manual for your car. Do not mix in a fluid of a different base type just because the DOT number looks higher.

Symptoms and what they point to

• Pulsation through the pedal under braking: uneven pad transfer or rotor thickness variation. Measure rotor thickness at several points around the disc; if it is near or below the discard figure, replace rather than machine.
• Soft or sinking pedal that bleeding does not fix: swollen flexible hoses, or a master cylinder bypassing internally.
• One corner dragging, or heat and a burning smell from a single wheel: a seized caliper piston or a frozen slide pin. Common on cars that have sat, and a rebuilt or new caliper is usually the answer.
• Parking brake will not hold on a hill: worn parking brake shoes or a scored drum surface inside the rear rotor hat. Replacing rear rotors also replaces that drum surface.
• Brake warning lamp on with a falling reservoir level: a leak. Inspect the front hoses first, given the recall history above, then lines and calipers.

When you replace pads, replace the abutment clips and hardware at the same time, and clean and lubricate the slide pins. New pads sliding in thirty-year-old rusted clips is the most common cause of a fresh brake job that still drags or squeals.

Bedding in and job difficulty

EBC states that most of its pads carry a break-in coating and that after the first 100 miles or so there is nothing more to do unless you intend to drive aggressively. EBC also notes that with spirited driving, pads may emit odor or smoke for up to about 300 miles as surface volatiles burn off at temperatures of 400-500 degrees C, and that new pads on used rotors extend bedding times significantly because of rotor surface irregularities. That last point is the argument for replacing pads and rotors together rather than putting new pads on marginal discs.

As a job, front pads and rotors on a Stealth are a moderate DIY task: a few hours with a jack, stands, a torque wrench and a caliper piston tool. The rear is more involved because of the parking brake mechanism inside the rotor hat, and the AWD cars are tight around the rear calipers. Torque every fastener to the value in the factory service manual for your year and drivetrain, and bleed the system properly if any hydraulic line was opened. Everything you need for the job is in our brake parts catalog.

Frequently Asked Questions

Do 1994-1996 Stealth brakes bolt onto a 1991-1993 car?

On the AWD cars, moving to the later front and rear brakes is the standard upgrade path because both sets are factory parts for the same chassis. You need the later rotors and calipers as a matched set, and you must confirm wheel clearance, since the later front rotor is 314 mm against the earlier 295 mm. Verify fitment for your exact car before ordering.

Does the Dodge Stealth have rear drum brakes?

No. All Stealths use rear disc brakes. The parking brake is a separate small drum built into the hat of the rear rotor, which is why people sometimes mistake it for a drum brake car.

Which EBC pad should I buy for a street-driven Stealth?

If you want low dust and quiet operation and you never see a track, Redstuff. If you drive the car hard on the road or do occasional track days, Yellowstuff, accepting more dust. Greenstuff 2000 suits the rear axle or a lighter-duty setup. EBC itself steers heavier, faster cars away from Greenstuff and toward Redstuff.

Can I resurface my old Stealth rotors instead of replacing them?

Only if they measure above the discard thickness stamped on the rotor and listed in the factory service manual, with enough material left after cutting. Front rotors on the AWD cars start at 30 mm and rears at 20 mm when new, and most surviving originals have already been machined at least once.

Why is my pedal still soft after a full bleed?

The usual causes are swollen flexible hoses or a master cylinder that is bypassing internally. Given the 1996 front brake hose recall on this platform, inspect and replace the front hoses before chasing anything more expensive.

Do I need a big brake kit for a Stealth R/T Twin Turbo?

For street driving, no. The factory four-piston front calipers on the AWD cars are capable hardware when the pistons are free, the hoses are new, the fluid is fresh and the pads match how you drive. Spend on those items first and see how the car feels before considering anything larger.
